( ) USER MANUAL EN
WARNING: NEVER PLUG IN THE FAN WHEN IT'S TAKEN
APART, THIS MAY CAUSE ELECTRICAL HAZARDS.
READ AND SAVE THESE IMPORTANT SAFETY
INSTRUCTIONS BEFORE USING THIS FAN
Safety precautions:
Only connect the fan to an earthed socket with a
corresponding voltage as mentioned on the article.
- Use the fan only as described in this manual.
- This product is intended for household use ONLY.
- Not for commercial, industrial, or outdoor use.
- To protect against electrical shock, do not immerse
unit, plug or cord in water or any other liquids.
- Do not spray the fan with liquids.
- Do not cover the fan.
- Do not use in humid spaces or near a sink.
- Do not use in the presence of explosive and/or highly
fl ammable fumes.
- Do not place the article or any part of it near open
fi re or another heat source.
- Place always out of children's reach.
- Children being supervised not to play with the
appliance.
- Always place on a level surface.
- Remove all objects in the direct vicinity of the article
in order not to block the swerving mechanism.
- Never put anything through the ventilation grid and
always keep under supervision when switched on.
- Do not place near an open window.
Always unplug from socket when:
- not in use
- moving the article from one location to another
- servicing parts, and before cleaning the article
Do not use when:
- plug or cord are damaged
- the article has fallen
- the article is not functioning properly
- the article is damaged in any way
Do not hang or mount fan on a wall or ceiling.
Do not operate without fan grills properly in place.
When the cord is damaged it has to be replaced by a
recognized electrician.
Before first use
Remove all packaging material from the appliance and
put the completely assembled fan on a stable, flat and
anti-skid surface.
Only connect appliance to mains supply after the fan
has been fully assembled.
Assembly
1. Loosen the screws at the pedestal (picture 1).
2. Place the base plate to the lower side of the pedestal
and secure it with washer and screw tightly (picture 2).
3. Place the Extension pole on top of the stand post and
tighten the knob fi rmly (picture 3).
4. Loosen the two screws below motor-housing
(picture 4).
5. The upper side of pedestal has one notch and opposite
one open slot (picture 5).
6. Place the motor unit on the upper side of the pedestal
pipe (picture 6). The notch on the pedestal is at the left
hand side at the back of the fan guard.
7. Insert the connection screw through the rectangular
opening (picture 7).
8. Screw the tilt-range knob as shown on picture 8.
Screw with a screw driver the small screw into the
provided screw hole (picture 9). Afterwards secure the
connection screw with the tilt adjustment knob tightly
(picture 10).
9. Place the front-side fan-guard at the backside fan-
guard and assemble it with the screws by using a screw
driver.
Attention: Always pull the plug before opening the
fan-guard. Risk of injury!
1.
2. 2. 3.
4a. 4b.
5a. 5b.
6a. 6b.
7a. 7b.
2
8a. 8b.
9a. 9b.
10a. 10b.
Adjusting the height
Loosen the height adjustment knob and pull the
extension pole out of the stand post, up to the desired
height. Then fasten the knob again firmly.
Operation
The speed level of the fan propeller can be selected with
the rotary switch:
0 – Position 0: appliance is switched off
1 – Position 1: low speed
2 – Position 2: middle speed
3 – Position 3: high speed
Oscillation function (horizontal pivoting of the air flow)
can be selected with the button (2) at the motor unit
rear part.
Button pressed down: Oscillation ON
Button pulled up: Oscillation OFF
The inclination angle of motor unit can be adjusted by
the tilt-range knob and tilt-adjustment knob (picture 8
and 10).
Switch the appliance off after use and pull the plug.

Cleaning and maintenance

FIRST TAKE THE PLUG OUT OF THE SOCKET
Never immerse the appliance in water or let it have
contact with water.
Do not use chemical, steel, wooden or abrasive cleaners.
Only use a mild detergent and a damped cloth.
