QXE6.2C INTERCONNECTION
V2
Midbass Midbass
L R
Tweeter Tweeter
L R
+ IN – +WF- +TW- + IN – +WF- +TW-
+ L – + R –
Speaker Outputs at the Amplifier
IMPORTANT:
Please pay attention to the correct polarity (+ or -)
for all terminals and connections.
