ESX Quantum QXE6.2CV2 Bedienungsanleitung Seite 8

ENGLISH
SPECIFICATIONS
QXE6.2C
V2
2-Way Component System
Power Rating RMS 125 Watts
Power Rating Max. 250 Watt
Impedance 4 Ohms
Frequency Range 55 - 24000 Hz
16,5 cm (6.5") Midbass Speakers
Polypropylene Graphite Cones
30,5 mm Voice Coils
17 oz. / 482 g Magnets (Y30)
Installation Opening Ø 143 mm
Installation Depth 65 mm
25 mm (1") Tweeters
Silk Dome Neodymium Drivers
2-Way Crossovers
Tweeter Adjustment -2dB / 0dB / +2dB
Dimensions 57 x 31 x 80 mm
QXE6.2W
V2
Kickbass Speakers
Power Rating RMS 125 Watts
Power Rating Max. 250 Watt
Impedance 4 Ohms
Frequency Range 55 - 5000 Hz
Polypropylene Graphite Cones
30,5 mm Voice Coils
17 oz. / 482 g Magnets (Y30)
Installation Opening Ø 143 mm
Installation Depth 65 mm
8
QXE6.2T
V2
25 mm (1") Tweeter Set
Silk Dome Neodymium Drivers
Power Rating RMS 125 Watts
Power Rating Max. 250 Watts
Impedance 4 Ohms
Frequency Range 3500 - 24000 Hz
6 dB Cable Crossovers with Tweeter Protection
Dimensions Ø 41 x 12 mm
QXE62
V2
2-Way Coaxial Speakers
Power Rating RMS 100 Watts
Power Rating Max. 200 Watts
Impedance 4 Ohms
Frequency Range 55 - 22000 Hz
Polypropylene Graphite Cones
30,5 mm Voice Coils
17 oz. / 482 g Magnets (Y30)
20 mm Silk Dome Neodymium Tweeters
Installation Opening Ø 143 mm
Installation Depth 64 mm
