Yedoo RUNRUN Bedienungsanleitung Seite 9

Installation manual
14.
Fasten the end of the brake cable in
the lock and secure with the cable tie,
then trim the tie (applies to both front
and rear brake).
EN
15.a
1 1
Adjustment of brakes – Mezeq / Four
On the front as well as the rear wheel,
check, if the disc of the brake does
not scrape the brake pad. If so, loosen
the adjusting screws (1) and set up the
position of both pads so that their entire
surface would be parallel with the disc,
then fasten the adjusting screws again.
15.b
3
2
The distance between the brake pads
and the disc should be as small as
possible. You can set it up using an
adjustment roller (2), which adjusts the
tension of the brake wire. If this is not
enough, you may loosen the wire in the
anchor bolt (3).
10
