Before using the power supp‫ا‬y, a!!ow it to warm up
to room temperature for
hour to prevent condensat!on accumu!atlng in the .
one
C.MPATIB.LITY
The be ٩u!et! Pure Power ,1 series power supp!ies are
compat‫ا‬b‫ا‬e with all recent
popular power supply and motherboard specifications
such
٠ Intel ATX12V Power Supply Design Guide Version 2.4
(and downwardly
compatible to V2.31, V2.3, V2.2, V2.01, V2.0 )
- A‫ًا‬x System Design Guide Version 2.2 and Version
2.1
"BIX Version 1.0a
" Ε-ΑΤΧ Server Mottierboards via 8-Pin connector
" EPS 12V version 2.92 (700W/600W)
" Intel C6/C7 Status for the new processor generation
" Energy Star 6.1 guidelines
" ErP guidelines
4. INSTALLING YOUR NEW POWER SUPPLY
Please read ,,Safety instructions" before you begin
the installation.
Note: You will need a screwdriver to fit the power
supply in your PC. Only use the
screws provided with the power supply because they
have the correct thread.
Caution; Only use the supplied cable set. Using cables
that were not included (e.g.
cables of older power supply unit series) may lead
to defects!
First remove your old power supply. To do so, proceed
as follows:
" Carefully disconnect your PC from any power sources
and unplug all cables
connected to the PC.
" Open the PC case, taking care to follow ttie manufacturer's
instructions.
" Disconnect all plugs from the motherboard and all
other components, such as
FDDs, HDDs, or optical drives. Make sure that there
are no pi'ugs from the old
power supply connected to any of the components.
" Now remove the screws at the rear of the power supply
and carefully pull the
power supply out of the PC case. Take special care that no cables get caught in
the components and damage them.
Fitting your new be quieti Pure Power 11 power supply;
" Place the new power supply in the space provided
in the PC case and connect
to the rear panel using the four screws provided. Do
not use excessive force.
5
