Operation:
1. Make sure the charging receptacle is securely covered with the rubber flap first.
See fig 6. Press the power button first, the battery indicator light will turn on. Then
place the vacuum in the water. See fig 6.1.
As the device is used, the battery indicator light will decrease showing the status of the
battery. When battery indicator is flashing one light, you must recharge the device
immediately. If not done so, the light will flash for a few minutes, the vacuum motor will
stop and the indicator light will turn off. See fig 6.2. Press the power button to view the
battery charge status.
Note: Always turn off the power button when the device is not in use or during long term
storage in order to prevent damage to the battery.
Fig 6
2. Carefully "sweep" the surface of the spa or pool to remove debris.
3. Check and empty the filter bag/micro-filter bag regularly during and after each use.
4. Reverse the above installation steps to remove and empty the filter bag/micro-filter bag.
Note: Rinse vacuum body, cover and filter bags with a garden hose before reassembling.
Maintenance and long term storage:
1. Turn off the vacuum before cleaning, servicing and maintenance. Regularly check all
components for sign of damage. Discard and replace damaged components immediately.
2. Using the installation instructions in reverse, disassemble the vacuum. Clean all the
components with water, and make sure all components are thoroughly dry before storage.
3. Store the product and accessories in a dry, temperature controlled, between 0º – 40ºC
(32º – 104ºF), storage location.
4. To protect and extend the life of the battery, make sure the battery is charged before
long term storage, and charge the battery every 3 months thereafter.
5. The original packing can be used for storage.
TROUBLE
VACUUM
• Charge the product then turn on the unit. Ensure the power button is on.
• Keep the vacuum body under the water.
DOESN'T WORK
LOW SUCTION
• Choose the suitable bag for filtering and install the filter bag(s) correctly.
• Check and empty the filter bag(s) regularly during and after each use.
• Check for any sand or deposits in the vacuum.
• Check if the battery power is too low. If it is too low, recharge it.
• Contact Intex Service Center.
CHARGING
• Plug the charger into the main electrical outlet first, then connect the cable into
FAILED
• Ensure the charger cable is securely inserted into the charging receptacle, the
DOESN'T CLEAN
• Check if the battery power is too low. If it is too low, recharge it.
• Use the correct vacuum head: use the large vacuum brush head for flat open
THE POOL
• Use the correct filter bag, see "Installation" section.
• Ensure the vacuum head or nozzle is close to the surface of the wall or floor, and
• The bristles of the vacuum brush head are worn out, replace a new brush head.
• For heavy stains on the pool wall, it's recommended emptying the pool and scrub
SAVE THESE INSTRUCTIONS
(128IO) ZR200 RECHARGEABLE POOL VACUUM ENGLISH SIZE: 4.875" X 7.25" 05/25/2023
the vacuum body charging receptacle.
indicator light should be on.
surfaces, and the vacuum nozzle head for corners, steps and uneven surfaces.
reduce the sweeping movement and speed during vacuuming.
the wall with mild detergent.
Page 4
Fig 6.1
SOLUTION
128
IO
Fig 6.2
