Installation:
1. Insert the filter bag with gasket (2) into the vacuum body (1). See fig 3.1.
For vacuuming fine-small particles: insert the micro-filter bag (6) into the filter bag with
gasket (2), making sure the micro-filter bag "wraps over" the filter bag gasket (2). Then
place the entire filter bag with the micro-filter bag into the vacuum body. See fig 3.2.
2. Install the vacuum body cover (3) onto the vacuum body (1). See fig 3.3.
Note: When removing the vacuum body cover (3), press the spring button to release the
vacuum body cover. See fig 3.4.
2
Fig 3.1
3. Attach the desired cleaning head accessory to the vacuum body cover. See fig 4.
Note: Make sure the arrow on the vacuum body cover (3) matches the arrow on the
vacuum brush head (4) or vacuum nozzle (5).
4. Attach the aluminum pole (8) by squeezing the spring buttons and inserting into handle
of the vacuum body (1). Check the buttons "pop" into the holes. Adjust the length of the
shaft by unlocking, extending and locking each section accordingly. See fig 5.
The vacuum body will not operate unless it is submerged in water. Water flow
from sides of the vacuum body indicates the product is working.
SAVE THESE INSTRUCTIONS
(128IO) ZR200 RECHARGEABLE POOL VACUUM ENGLISH SIZE: 4.875" X 7.25" 05/25/2023
2
6
1
1
2
1
Fig 3.2
2
2
Fig 5
IMPORTANT
Page 3
Fig 3.3
Fig 4
128
IO
3
Fig 3.4
