Legende
12 V, PE, Modbus-Zähler, CP, PP
(Molex Nano-Fit 105310-3508)
Anschluss Ethernet (ETH2)
Anschluss Ethernet (ETH1)
Erweiterungsanschluss (USB-Typ-A)
SIM-Kartenhalter (3FF, Micro)
LED Status Laderegler
Antennenbuchse 4G-Modem (SMA)
Konfigurationsschnittstelle (USB-Typ-B)
Stecker-Verriegelung, Steuerrelais
(Molex Nano-Fit 105310-4508)
Optokopplereingang (Molex Nano-Fit 105310-3508)
Anschluss integriertes Power-Modul (IPM) (Micromatch, 20-polig)
LED Aktivität Ethernet 2
LED Aktivität Ethernet 1
integrierte WiFi-Antenne
Antennenbuchse 4G-Modem (U.FL)
4x RGB LED (Zustand Ladestation)
RCD Typ A
Typ-2-Steckdose
Tabellarische Daten
Isolationskoordination nach IEC 60664-1 bzw. IEC 60664-3
Bemessungsspannung ........................................................12,5 V / 24 V
Überspannungskategorie (Klemme e) .................................................III
Verschmutzungsgrad ............................................................................ 2
Bemessungsstoßspannung ............................................................ 800 V
Einsatzhöhe .............................................................. ≤ 2000 m über NN
Versorgungsspannung DC 12 V (Klemme P)
Versorgungsspannungsbereich U
max. Leistungsaufnahme................................................................12 W
durchschnittliche Leistungsaufnahme ..............................................6 W
Eingänge
Eingangsspannung (HIGH) ........................................DC 11,4 V...25,2 V
Eingangsspannung (LOW) ............................................................DC 0 V
Eingangsstrom ...................................................................2,3...6,4 mA
max. Potentialunterschied zu PE/GND ............................................50 V
Eingang PE (Klemme A (PE, PE))
............................DC 11,4 V...12,6 V
s
Legend
12 V, PE, Modbus meter, CP, PP
A
(Molex Nano-Fit 105310-3508)
B
Connection Ethernet (ETH2)
C
Connection Ethernet (ETH1)
D1, D2 Extension connection (USB type A)
E
SIM card holder (3FF, micro)
F
LED status charge controller
G
Antenna socket 4G modem (SMA)
H
Configuration interface (USB type B)
Connector locking device, control relay (
K
Molex Nano-Fit 105310-4508)
L
Optocoupler input (Molex Nano-Fit 105310-3508)
P
Connection integrated power module (IPM) (Micromatch 20-pole)
Q
LED activity Ethernet 2
R
LED activity Ethernet 1
S
integrated WiFi antenna
T
Antenna socket 4G modem (U.FL)
U
4x RGB LED (status charging system )
RCD type A
Type 2 socket-outlet
Tabular Data
Insulation coordination acc. to IEC 60664-1 or IEC 60664-3
Rated voltage ......................................................................12.5 V / 24 V
Overvoltage category (terminal e) .......................................................III
Pollution degree ................................................................................... 2
Rated impulse voltage ................................................................... 800 V
Operating altitude AMSL ......................................................... ≤ 2000 m
Supply voltage DC 12 V (Terminal P)
Supply voltage range U
max. power consumption ...............................................................12 W
average power consumption ............................................................6 W
Inputs
Input voltage (HIGH) .................................................DC 11.4 V...25.2 V
Input voltage (LOW) .....................................................................DC 0 V
Input current ............................................................... 2.3 mA...6.4 mA
max. potential difference to PE/GND ..............................................50 V
1
Input PE (Terminal A (PE, PE))
ICC1314_D00520_00_Q_DEEN / 02.2025
...........................................DC 11.4 V...12.6 V
s
ICC1314
