Step 6: Install Handlebar
95
EN
Assembly Instructions
PARTS LIST
A. Pull the steel wire to bring the Sensor
Middle Wire (95) connector passes
through the slot in the center of the
Handlebar (5) mounting piece.
B. Place Handlebar (5) on Handlebar Post (4)
as shown. Make sure the holes are aligned.
Secure the Handlebar (5) to the Handlebar
Post (4) as shown in the figure by using
tool D-#6, 4PCS Hexagon Socket Cheese
Head Screw (10) and 4PCS Washers (17).
012
