Error codes
Version RH digital KT/C:
The LED displays (C and D) will start to flash and display a code when a fault is
present. The fault codes and troubleshooting procedure are as follows:
Error code LED Cause Solution
E 2 G Inner temperature too Switch off the unit and allow it cool down.
high Check that the ventilation slots on the bottom
are not blocked and that cooling air can
circulate freely.
- S - G Safety circuit is triggered Reduce the temperature setpoint or reset the
safety circuit where necessary.
E 2 D No pulse at the reading Switch off the unit. Trace the external cause for
fork (faulty reading fork, blocking the stirring drive. If no external cause
faulty motor or motor can be determined, clean the unit and return it
blocked) for repair.
E 6 G Contact plug not Plug in contact plug
plugged in
Breakage and/or short- Replace contact thermometer
circuit of the contact
thermometers
Other Switch off the unit. Clean and return it for
codes repair.
Version RH basic 2 and RH basic KT/C:
The warning light (I) flashes to indicate that a fault is present. To remove a fault
condition, proceed as follows:
• Switch off the unit and allow it to cool down.
• Trace and remove the cause of the fault.
• Switch on the unit.
If the fault persists, clean the unit and return it for repair.
16
Mounting - Support rod H 16 V
The H 16 V support rod can be screwed into the threading on the right behind
the housing as follows:
• Remove the plastic cap and washer from the support rod and screw off the
hex nut.
• Place the washer and hex nut on the beginning of the threading on the
housing and hold them in place.
• Screw the support rod into the nut and threading of the housing and counter-
tighten the hex nut.
Maintenance and Cleaning
The device is maintenance-free. It is only subject to the natural wear and tear of
components and their statistical failure rate.
Cleaning
› For cleaning disconnect the mains plug!
› Use only cleaning agents which have been approved by IKA to clean the
devices:
Water containing surfactant / isopropyl alcohol.
› Wear protective gloves during cleaning the devices.
› Electrical devices may not be placed in the cleansing agent for the purpose of
cleaning.
› Do not allow moisture to get into the device when cleaning.
› Before using another than the recommended method for cleaning or
decontamination, the user must ascertain with IKA that this method does not
destroy the device.
Version RH basic KT/C and RH digital KT/C
Information for Care and Maintenance of the Heating Plate with Technical
Enamel Coating
The technical enamel makes the heating plate easier to care fort and more
resistant to acids and bases. Because of it, however, the heating plate is also
more susceptible to extreme fluctuations in temperature and the force of
impact. This can result in cracks forming or the coating flaking off.
Make certain that the bottom of the placing vessel is even, clean and dry. The
bottom of the placing vessel must not have any sharp grooves, sides or edges.
We recommend most strongly that you clean the heating plate regularly.
Spare parts order
› When ordering spare parts, please give:
- device type.
- serial number, see type plate.
- position number and description of spare part, see www.ika.com.
- software version.
Repair
› Please only send devices in for repair that have been cleaned and are free of
materials which might present health hazards.
› For repair, please request the "Safety Declaration (Decontamination
Certificate)" from IKA or use the download printout of it from IKA website at
www.ika.com.
› If your appliance requires repair, return it in its original packaging. Storage
packaging is not sufficient when sending the device - also use appropriate
transport packaging.
Accessories
RS 1 set of stirring bars H16 V support rod
RSE PTFE stirring bar remover
Recommended IKA-stirrers
TRIKA-stirring bars: PTFE, triangular, length 55 mm
IKAFLON-stirring bars: PTFE diameter 8 mm, lengths 25, 30, 40 and 50 mm
For more accessories see www.ika.com.
Warranty
In accordance with IKA warranty conditions, the warranty period is 24 months.
For claims under the warranty please contact your local dealer. You may also send
the machine direct to our works, enclosing the delivery invoice and giving reasons
for the claim. You will be liable for freight costs.
The warranty does not cover wearing parts, nor does it apply to faults resulting
from unintended use or insufficient care and maintenance contrary to the instruc-
tions in this operating manual.
