Informationen zu den beiliegenden Anleitungen......9 Weitere Anleitungen............. 9 Aktuelles................9 Copyright und Marken............10 Vorbereitung ................11 COMfortel WS-650 IP im Rack montieren ....... 11 Inbetriebnahme ..............13 COMfortel WS-650 IP anschließen.......... 13 Konfigurationsmanager öffnen..........14 COMfortel WS-650 IP einrichten ..........14 Netzwerkeinstellungen ............
Seite 4
Network settings..............28 Security settings..............28 SIP settings ................ 28 Configuring a DECT handset ..........29 Registering a DECT handset to the COMfortel WS-650 IP ..30 Appendix ................31 Cleaning the COMfortel WS-650 IP ......... 31 Lizenzen/Licenses ..............32 End user license agreement (EULA) ........
Wichtige Informationen Wichtige Informationen Dieser Abschnitt enthält die für einen sicheren Betrieb notwendi- gen Informationen. Bevor Sie den COMfortel WS-650 IP in Betrieb nehmen, lesen Sie unbedingt die hier aufgeführten Sicherheitshinweise und machen Sie sich mit der bestimmungs- gemäßen Verwendung des Geräts sowie den technischen Daten vertraut.
Sie Ihren Fachhändler. Lesen Sie die zum Gerät gehörenden Anleitungen und bewahren Sie diese zum späteren Gebrauch auf. Bei dem COMfortel WS-650 IP handelt es sich um einen IP- DECT Mehrzellen-Server zum Aufbau eines IP-DECT Wireless- Systems innerhalb von geschlossenen Gebäuden.
Seite 7
Der COMfortel WS-650 IP verwaltet alle Komponenten des Wire- less-Systems und die IP-Schnittstelle zur TK-Anlage. Der COMfortel WS-650 IP kann bis zu 30 DECT-Handsets und bis zu 32 gleichzeitige Sprachkanäle verwalten. Nach der Frei- schaltung aller Sprachkanäle kann der COMfortel WS-650 IP bis zu 4096 DECT-Handsets und bis zu 1024 gleichzeitige Sprach- kanäle verwalten (schrittweise skalierbar auf 30, 150, 1500 und...
2 Steckplätze für Media-Ressourcen Farbe grau Abmessungen (B x 440 mm x 199 mm x 44 mm H x T) Gewicht ca. 2350 g Sicherheit Umwelthinweis Entsorgung Entsorgen Sie das Verpackungsmaterial im Interesse des Umweltschutzes ordnungsgemäß. COMfortel WS-650 IP - Inbetriebnahme V02 04/2014...
Eine ausführliche Bedienungs- und Konfigurationsanleitung fin- den Sie im Internet (siehe www.auerswald.de unter Service > Produkte > Telefone > COMfortel WS-650 IP > Dokumenta- tion). Beachten Sie zusätzlich die Informationen zu Garantie, Service, Umwelt, CE-Zeichen und Konformitätserklärung im Bei- leger „Garantiebedingungen, Informationsservice“.
Mitteilung des Inhalts, auch auszugsweise, ist nur mit unserer ausdrücklichen Genehmigung gestattet. Zuwiderhand- lung verpflichtet zu Schadenersatz. Alle Rechte vorbehalten. Auerswald GmbH & Co. KG, 38162 Cremlingen, 2014 Alle genannten Marken sind Eigentum der jeweiligen Hersteller. COMfortel WS-650 IP - Inbetriebnahme V02 04/2014...
Vorbereitung Vorbereitung Dieser Abschnitt beschreibt die vor der Inbetriebnahme des Geräts notwendigen Vorbereitungen. COMfortel WS-650 IP im Rack montieren Der COMfortel WS-650 IP ist für die Montage in einem 19-Zoll- Rack vorgesehen. Voraussetzungen – Werkzeug und Material: Die im Lieferumfang enthaltenen Befestigungswinkel und...
Seite 12
Kondensation, aggressiven Flüssigkeiten und Dämpfen. Befestigen Sie die Befestigungswinkel mithilfe von 4 Schrau- ben am Gehäuse. Schieben Sie das Gehäuse in das Rack ein. Befestigen Sie das Gehäuse mithilfe von 4 Schrauben an den Befestigungswinkeln im Rack. COMfortel WS-650 IP - Inbetriebnahme V02 04/2014...
Stecken Sie einen Stecker des Patchkabels in die RJ45- Buchse auf der Vorderseite des Geräts. Stecken Sie den anderen Stecker des Patchkabels in eine vorhandene Netzwerksteckdose. Verbinden Sie das Gerät mit einer 230-V-Netzsteckdose. COMfortel WS-650 IP - Inbetriebnahme V02 04/2014...
Kenntnis der IP-Adresse des COMfortel WS-650 IP Hinweise: Ist im lokalen Netzwerk ein DHCP-Server eingerichtet, bezieht der COMfortel WS-650 IP seine IP-Adresse von diesem DHCP- Server. Die IP-Adresse können Sie über den DHCP-Server und die Mac-Adresse des COMfortel WS-650 IP oder über UPnP ermitteln.
Öffnen Sie die Seite Configuration > General. Wählen Sie unter IPv4 im Listenfeld Method eine der folgen- den Optionen: Use Static IP Address: Dem COMfortel WS-650 IP wird eine feste IP-Adresse zugewiesen (empfohlen). DHCP assigned: Der COMfortel WS-650 IP bezieht seine IP-Adresse automatisch von einem DHCP-Server.
Geben Sie im Eingabefeld Standby text den Text ein, den das DECT-Handsets im Ruhezustand anzeigen soll. Geben Sie unter SIP im Eingabefeld Username/Extension die interne Rufnummer des DECT-Handsets ein, die Sie in der TK-Anlage eingetragen haben, z. B. 100. COMfortel WS-650 IP - Inbetriebnahme V02 04/2014...
Richten Sie mind. eine COMfortel WS-Base Mehrzellen- Basis ein (siehe Anleitung der COMfortel WS-Base). Hinweis: Zum Betrieb eines IP-DECT Mehrzellen-Systems mit einem COMfortel WS-650 IP benötigen Sie mind. eine COMfortel WS-Base Mehrzellen-Basis. Melden Sie die DECT-Handsets am COMfortel WS-650 IP...
Anhang Anhang Haben Sie Ihren COMfortel WS-650 IP in Betrieb genommen und eingerichtet, finden Sie in diesem Abschnitt über Bedienung und Einrichtung hinausgehende nützliche Informationen. COMfortel WS-650 IP reinigen • Reinigen Sie das Gehäuse mit einem leicht feuchten Tuch oder einem Antistatiktuch.
This section contains information that is necessary for you to operate your equipment safely. Before you bring the COMfortel WS-650 IP into operation, it is absolutely essential for you to read the safety information described here and familiarise yourself with the intended use of the device as well as the tech- nical data.
Read the instructions for the device and keep them for future reference. The COMfortel WS-650 IP is an IP-DECT Multicell Server designed to set up an IP-DECT Wireless System in enclosed buildings. For your IP-DECT Wireless System you will require the following...
The COMfortel WS-650 IP can manage up to 30 DECT handsets and up to 32 voice channels simultaneously. After the activation of all voice channels the COMfortel WS-650 IP can manage up to 4096 DECT handsets and up to 1024 voice channels simultane- ously.
Consult your local governmental authorities for ways to dispose of the device in a proper and environmentally safe way. If you would like us to handle disposal, please send the device to We only accept pre-paid shipments. COMfortel WS-650 IP - Setup V02 04/2014...
Offenders will be subject to claims for dam- ages. All rights reserved. Auerswald GmbH & Co. KG, 38162 Cremlingen, 2014 All trademarks mentioned are the property of the corresponding manufacturer.
Preparation This section describes the preparations required before commis- sioning the device. Mounting the COMfortel WS-650 IP in the Rack The COMfortel WS-650 IP is designed to be mounted in a 19" rack. Requirements – Tools and materials: The support bracket and screws included in the scope of...
Seite 25
Use 4 screws to attach the support brackets to the casing. Push the casing into the rack. Use 4 screws to secure the casing via the support brackets in the rack. COMfortel WS-650 IP - Setup V02 04/2014...
Security settings (page SIP settings (page Configure a DECT handset (page Registering a DECT handset to the COMfortel WS-650 IP (page Default settings when the equipment is supplied – Access data for the Configuration Manager : User name: admin Password: admin (password before firmware version 14A: ip6000) –...
Commissioning The LED on the front cover flashes red followed by a steady green if the COMfortel WS-650 IP has been con- figured. Opening the Configuration Manager Requirements – Existing network connection between the PC and the COMfortel WS-650 IP –...
Open the Configuration > General page. Select one of the following options from the Method list field displayed under IPv4: Use Static IP Address: The COMfortel WS-650 IP is assigned a fixed IP address (recommended). DHCP assigned: The COMfortel WS-650 IP gets its IP address automatically from a DHCP server.
Enter the PBX's IP address in the Default domain entry field. Select the priority of codecs in the Codec priority list fields. Note: During operation on Auerswald PBXs, we recommend the following codec priority configuration: 1: PCMA/8000 (G.711 A-law) 2-6: None During operation on PBXs from other manufacturers, configure the codec priority according to the available codecs.
Note: To operate an IP-DECT Multicell System with the COMfor- tel WS-650 IP you require at least one COMfortel WS-Base multi- cell base. Register the DECT handsets to the COMfortel WS-650 IP. Registering a DECT handset to the COMfortel WS-650 IP Switch on the DECT handset.
Only clean the casing of the device with a slightly damp cloth or an anti-static cloth. Caution: Cleaning agents may damage the surface. Do not use caustic or solvent-containing cleaning agents. COMfortel WS-650 IP - Setup V02 04/2014...
Products. Such warranties, however, are the sole and exclusive liability of Auerswald, and Auerswald is not authorized to make any warranties to you for or on behalf of the manufacturer of the Products. 5. You agree that (1) the manufacturer of the Product is a third-party beneficiary of these terms, and (2) the license, restrictions and confidentiality provisions set forth herein are made for the express benefit of the manufacturer of the Product and are enforceable by Auerswald’s licensor as well as Auerswald.
