GB
LEGEND FUSES:
F1: 5A fuse connected to the vehicle battery to power the side marker lights
F2: 20A fuse connected to service battery to power the fridge.
F3: 7.5A fuse connected directly to service battery to power control boards if necessary
(e.g. fridge, etc.)
F4: 10A fuse connected directly to service battery
F5: 10A fuse connected directly to service battery
F6: 10A fuse connected directly to service battery
F7: 10A fuse connected directly to service battery
F8: 15A fuse connected directly to service battery
F9: 15A fuse connected to light master switch to power Lights_1
F10: 15A fuse connected to light master switch to power Lights_2
F11: 7.5A fuse connected directly to service battery to ignition and external light switch
F12: 15A fuse connected to AUX switch
F13: 10A fuse connected to water pump switch
Attention:
When replacing faulty fuses, observe the correct amperage.
OPERATION:
Services activated from control panel:
Internal light outputs (lights_1 and lights_2), external light, pump and aux are activated directly by the relevant
buttons on the control panel.
-If the service battery voltage remains under 10,5V for over a minute, the shunt automatically turns off all the power
for lights, pump, external light and aux. To recharge press the relevant keys on the control panel. If the battery is
still under 10,5V, it will be deactivated again after one minute. In this case is advisable to disconnect all loads with
the battery main switch and recharge the battery services within 2 days.
Side marker signal:
The side-marker output can be activated with a negative control (negative) on the JP13 block, pin 5, or
with a positive control (+12V) on the JP13 block, pin 4.
Recharging vehicle battery:
If there is the main supply 230V, the shunt charges the car battery with a current of about 2A. The charge is activated
automatically when the battery voltage exceeds the services of the car battery.
Services activated by D+:
(1)
The coupler relay and the fridge relay are enabled immediately in one of these two conditions:
+Key
KEY-ON
JP13 pin 1
1)
+12V
(1)
The coupler relay recharges the service battery with the alternator when the engine is running.
The fridge relay powers the three purpose fridge at 12V when the engine is running.
With the engine running the external light automatically turns itself off.
(1)
If there is a connection between J6 and J7 the coupler relay is not enabled.
(presence of external DC / DC converter)
ATTENTION: DC / DC converter:
If you use the DC / DC converter to charge the services battery, make the connection between J6
and J7.
In this mode the coupler relay (RE1) is not enabled when
If the vehicle not in use and the connection 230V is not present disconnect the battery service with the battery main
switch.
SHUNT NE356_D
D+
D+
JP13 pin 6
on
+Key
KEY-ON
JP13 pin 1
2)
+12V
the engine is running.
6
GB
+Alternator
G
JP13 pin2
+12V
