GLOBBER FLOW Benutzerhandbuch Seite 6

Keep the instructions for future reference.
NF-EN-14619: 2019
READ THE INSTRUCTIONS PROVIDED BY THE MANUFACTURER BEFORE
USING. MAXIMUM WEIGHT: 50 kg
Warnings
- The scooter is suitable for adolescents and adults. It is not a toy, but sports
equipment for physical training. It is not intended for use in extreme sports, such
as jumping, ollie ramps, etc. This product should never be used at a skate park for
an "aggressive" use (challenging skateboarding moves, etc.).
- U se with caution on a flat, clean, dry surface and, if possible, away from other
users, and obey the road safety rules.
- C heck local laws regarding scooter use; respect all the traffic rules and signs.
Stay away from other pedestrians or users on public roads.
- B est when used on a flat, dry surface free of gravel and grease. Avoid bumps and
drainage grates that might cause an accident.
- Warning! Protective equipment consisting of wrist protectors, gloves, knee pads,
helmet, and elbow pads should be worn.
- Do not use on wet days or on wet ground.
- Store the product in a cool, dry place. Avoid direct sunlight.
Using the scooter
• Before and after each use: To prevent pinched fingers, carefully follow the
instructions of unfolding and folding. Make sure that the locking mechanisms are
securely locked:
- Check the height of the steering system and make sure that the nuts are
tightened and the handlebars and front wheel are perpendicular.
- Check all of the connection elements: The brake, the quick release system of the
steering column, and the wheel axles must be correctly adjusted and must not
be damaged.
- Also check the tire wear.
• Braking:
- A brake is located atop the rear wheel; when necessary, press down on it to slow
down. Press down gradually to prevent skidding or loss of stability. The metal
brake may heat up after multiple uses. Avoid touching it during and after use.
Assembling the product
- The folding and unfolding operations of the scooter are to be done by a single
person.
- D uring these operations, be careful you do not get your fingers stuck in the hinge
6
and locking system.
- Make sure that the locking devices are properly engaged.
1 - Unfold the scooter
D1: Unpack the folded scooter from its box.
D2: Push the black button located on the front underside of the scooter. At the
same time, pull the T-bar to unfold the scooter. Make sure you hear a click.
(If it is difficult to fold or unfold scooter, please use an M4 allen tool to loosen the
hex screw one turn as the photo shows. Don't loosen the hex screw too much; the
hex screw may be lost.)
D3: Pull out both parts of the T-bar handle from the double clips. Press in the
spring-loaded buttons and insert both into the tubes of the T-bar. Wiggle and turn
a bit until their spring-loaded locking buttons align with the holes and fix the whole
steering bar assembly in place.
Warning! Risk of injury by pinching!
Do not insert your fingers into the shaded area indicated
2 - Adjust the handle bar
D4: Open the fixing lug. Then press down the spring-loaded locking button and pull
the handlebar up or push it down with the other hand.
Choose the suitable locking hole and make sure the spring-loaded locking pin
snaps securely in place. The adjustable T-bar handle can be adapted in height to
suit the rider.
3 different positions are available.
Lock the fixing lug tightly and securely when you have finished adjusting the height.
3 - Self-standing mode
Push the black button located on the front underside of the scooter and fold back
the T-bar just a tad.
Release the button when the deck touches the ground. The scooter is now in
self-standing mode. You can now leave the scooter standing in that position. You
can park your scooter upright on any flat surface.
4 - Fold the scooter
D5: Push the black button located on the front underside of the scooter while
pulling on the metal T-bar, which will cause the steering column to close. Release
the button when the steering column begins to fold up. The button will position itself
in its locking position when the steering column is completely folded. Make sure
you hear a click.
