Use o the product
Function description
Insert the plug into the socket, press on/o
button, the machine is in strong mode and strong
indicator lights up.Press the mode button to
switch the sot mode and sot indicator lights
up.Press on/o button again, the machine stop
working.
Note:
1.When the dust over the Max line,please clean the dust
cup and MIF ilter in time.
2.For saety reasons, the UV light only works when two
micro switches are pressed simultaneously. Otherwise,
the UV light will automatically turn o.
3.The product is equipped with UV light.Do not view the
bottom o the machine , shine on plants when the power
is turned on to prevent UV rays rom causing harm to
human body or other objects.
Cleaning and maintenance
Note:
1. MIF ilter is available or sale at JIMMY distributor.
2.It is recommended to clean the dust cup in time ater
each use. When there is too much dust to cause MIF
blockage, it needs to be cleaned in time or replaced i
necessary.
Dust cup cleaning
1.Turn o the machine and unplug the power
cord. Then press the release button and lit
upward. (Figure 1)
2.Hold the dust cup and dust cup cover
separately , twist dust cup lid anticlockwise (Figure 2),lit up and remove it rom dust cup
to clean .(Figure 3)
MIF lter and Cyclone Cleaning
Hold the cyclone in one hand, pinch the "UP" logo with the other hand, and take out ilter
(Figure 4),Do Not tap the ilter in reverse side in case o ilter clog.(Figure5)
Clean the cyclone metal ilter with the attached mini brush.(Figure 6)
Ater cleaning dust cup ,MIF ilter and cyclone, assemble in reverse order. Rotate the dust cup
cover assembly into the dust cup.Ater hearing a "click" and the dot mark is aligned with the lock
position that is assembled in place.(Figure 7)
1
Dust cup lid assembly
Dust Cup
2
Up ribbon
MIF lter
4
Cyclone metal lter
Mini-brush
6
Release
button
Cyclone
3
Downward tap
Filter
5
Rotate dust cup lid
7
