DIMENSION SUB
U s e r m a n u a l
10
5. Installation
5.1. Installation precautions
Support dimensions
To ensure maximum stability of your audio video system, your support (TV cabinet etc.) must respect the following
minimum dimensions:
TV
115,5 cm minimum
40 cm minimum
Maximum weight supported
Dimension Sub has been designed to support the majority of modern flat screens. The combined weight of the
screen and its stand must not exceed 55kg.
TV stand dimensions
The dimensions of the subwoofer have been designed to entirely support the majority of flat screens. However, if the
depth of the TV stand is greater than the depth of the subwoofer, the TV stand can rest both on Dimension Sub and
Dimension. Thus, the system's total support surface is as follows:
115 cm minimum
35 cm
minimum
Anti slip feet
The height of the anti slip feet on Dimension Sub can't be adjusted.
