blum SERVO-DRIVE uno Bedienungsanleitung Seite 16

SERVO-DRIVE uno
SERVO-DRIVE uno for TANDEM / TANDEMBOX
SERVO-DRIVE uno supports the opening of drawers.
Orientation diagram: bottom mount waste bin solutions
4
2
1 3 6
Orientation diagram: top mount waste bin solutions
4
3
6
7
6
1
2
3
4
5
5
6
7
SERVO-DRIVE unit pre-mounted:
Bracket profile horizontal
1
Bracket profile adapter
2
Drive unit
3
Protection against dripping water
4
Blum transformer including cable
5
5
Blum-Distance bumper
6
2
1
BA-140/1ML-A
SERVO-DRIVE unit pre-mounted:
Attachment bracket
Drive unit
Transport protection
Protection against dripping water
Blum transformer including cable
Assembly device
Blum-Distance bumper
