OPERATION
Assembling
• Assembly must ensure that:
– only cold air is supplied
– no (hot air) backup occurs
– the tool is not subjected to a hot air flow from another tool
• The tool is protected against mechanical vibration and shaking
• No air blasts at temperatures over 100°C
Air supply
• If compressed air is used, an upstream oil and water separator must be connected.
• The tool must only be supplied with air up to a max. 60°C.
Betrieb
• The tool must be connected by a qualified electrician in accordance with the
circuit diagram on page 3.
• Fit the nozzle appropriate to the use.
• Connect the air supply at the compressed air connection (8).
• Set the air flow at the pressure reduction valve (3) (min. air flow, max. pressure - see
technical data page 2)
• Switch on at main switch (2)
• Set the required hot air temperature at the temperature regulator CSS (5).
• After use let the tool cool down by allowing cold air to flow through (avoiding a
build up of heat).
Attention: Never operate tool without air supply!
Function heat element protection
• If the heating element overheats, the heater is switched off through the converter
integrated in the connection box (4). The shutdown is indicated on the fault
indicator (6).
Function tool protection
• If the tool overheats, the heater is switched off through the converter integrated in
the connection box (4). The shutdown is indicated on the fault indicator (6).
Measures to take in the case of switching off through the heating element
protection and tool protection
• Switch off the tool at the main switch (2)
• Check the compressed air
• Check the air flow rate
• Check the through flow of air
• Switch on the tool at the main switch (2)
