The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains
socket elsewhere.
Product Description and
Specifications
Read all the safety and general instructions.
Failure to observe the safety and general in-
structions may result in electric shock, fire
and/or serious injury.
Please observe the illustrations at the beginning of this oper-
ating manual.
Intended Use
The power tool is intended for making separating cuts and
cut-outs in wood, plastic, metal, ceramic plates, rubber and
laminate/HPL (High Pressure Laminate) while resting firmly
on the workpiece. It is suitable for straight and curved cuts
with mitre/bevel angles of up to 45°. The saw blade recom-
mendations are to be observed.
Product Features
The numbering of the product features refers to the diagram
of the power tool on the graphics page.
(1) On/off switch locking mechanism
(2) On/off switch
a)
(3) Dust extraction hose
a)
(4) Dust extraction adapter
(5) Extraction outlet
(6) Base plate
(7) Sawdust blower device switch
(8) Guide roller
a)
(9) Saw blade
(10) Viewing window for Cut Control
a)
(11) Base for Cut Control
(12) Shock protection guard
(13) Handle (insulated gripping surface)
(14) Saw blade receptacle
a)
(15) Anti-splinter guard
(16) Accessory holder
(17) Bracket for guide roller
(18) Base plate screw
(19) Scale for mitre/bevel angles
a)
(20) 0° cut mark
a)
(21) 45° cut mark
a) This accessory is not part of the standard scope of delivery.
Technical data
Jigsaw
Article number
Bosch Power Tools
Jigsaw
Cut Control
Rated power input
No-load stroke rate n₀
Stroke
Max. cutting depth
– In wood
– In aluminium
– In steel (unalloyed)
Max. cutting angle (left/right)
Weight
Protection class
A) Weight without mains connection cable and without mains plug
The specifications apply to a rated voltage [U] of 230 V. These spe-
cifications may vary at different voltages and in country-specific mod-
els.
Noise/Vibration Information
Noise emission values determined according to
EN 62841‑2‑11.
Typically, the A-weighted noise level of the power tool is:
Sound pressure level 91 dB(A); sound power level
99 dB(A). Uncertainty K = 5 dB.
Wear hearing protection!
Vibration total values a
determined according to EN 62841‑2‑11:
Cutting boards with saw blade T 144 D:
a = 10 m/s
h,B
cutting sheet metal with saw blade T 188 A:
a = 11 m/s
h,M
The vibration level and noise emission value given in these
instructions have been measured in accordance with a
standardised measuring procedure and may be used to com-
pare power tools. They may also be used for a preliminary
a)
estimation of vibration and noise emissions.
The stated vibration level and noise emission value repres-
ent the main applications of the power tool. However, if the
power tool is used for other applications, with different ac-
cessories or is poorly maintained, the vibration level and
noise emission value may differ. This may significantly in-
crease the vibration and noise emissions over the total work-
ing period.
To estimate vibration and noise emissions accurately, the
times when the tool is switched off or when it is running but
not actually being used should also be taken into account.
This may significantly reduce vibration and noise emissions
over the total working period.
Implement additional safety measures to protect the oper-
ator from the effects of vibration, such as servicing the
power tool and accessories, keeping their hands warm, and
organising workflows correctly.
PST Easy
3 603 CA0 7..
W
−1
min
mm
mm
mm
mm
°
A)
kg
(triax vector sum) and uncertainty K
h
2 2
, K = 3 m/s ,
2 2
, K = 3 m/s .
1 609 92A 9H2 | (23.05.2024)
English | 13
PST Easy
●
500
3100
20
65
10
4
45
1.6
/II
