• Use the screws and plugs supplied to fasten the bracket
to the wall.
• Once the wall bracket is in place,
the MAX! Cube can be attached to
the wall bracket from above, with
the opening pointing down.
System set-up involves the following steps, which are de-
scribed below:

• Connecting the MAX! cube

• Installing the MAX! software
• Installing and teaching in the MAX! devices
• Setting up Internet control
1. Connect the MAX! cube to the power supply:
The MAX! cube draws its power supply from the plug-in
main adapter included in the scope of supply.
Attention: To avoid damaging the device, please
only use the original main adapter supplied with the
device for the power supply.
• Plug the USB main adapter supplied into a socket outlet.
• Connect the MAX! cube and the main adapter with the
USB cable. Use the USB port on the side of the device
(2) for this purpose (see diagram on page 16).
• The power LED starts to flash as soon as the MAX! cube
initiates a self-test.
18

6. Setting up the MAX! system

6.1 Connecting the MAX! cube
