Owner's Manual
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT
In order to receive a more complete assistance, please
register your product on www.whirlpool.eu/register
Before using the appliance carefully read the Safety
Instruction.
PRODUCT DESCRIPTION
1
2
3
4
CONTROL PANEL
1
1. LEFT HAND DISPLAY
2. PAUSE
To pause a cooking cycle
3. ON/OFF
For switching the oven on and off
and for stopping an active function
at any time.
4. BACK
For returning to the previous
screen.
2 3 4 5
5. ROTARY KNOB / 6
BUTTON
Turn this to navigate through
the functions and adjust all of
the cooking parameters. Press
to select, set, access or confirm
functions or parameters and
eventually start the cooking
program.
6. POWER
To adjust the temperature, grill
level or microwave power.
PLEASE SCAN THE QR CODE ON
YOUR APPLIANCE IN ORDER TO
REACH MORE INFORMATION
1. Control panel
2. Circular heating element
(non-visible)
3. Identification plate
5
(do not remove)
4. Door
6
5. Upper heating element/grill
6. Light
7. Turntable
7
6 7 8
SENSE 7. START
th
For starting functions and
confirming settings
8. TIME
For setting the time as well as
setting or adjusting the cooking
time.
9. RIGHT HAND DISPLAY
EN
9
