ULTIMATE SPEED CLIX I Montage-Und Sicherheitshinweise Seite 6

switch to „OFF".
4. Then unplug the 12V plug from the 12V vehicle
power socket.
5. Cleaning
Water penetrating into the housing can cause a
short circuit.
- Never immerse the heated seat pad in water.
- Ensure that water does not get into the heated
seat pad.
Improper handling of the heated seat pad can
cause damage.
- Do not use abrasive cleaners, brushes with metal
or nylon bristles and sharp or metallic cleaning
objects such as knives, scrapers and the like. This
will damage the surface.
- Never put the heated seat pad in the washing
machine.
1. Before cleaning unplug the 12V plug from the
12V vehicle power socket.
2. Let the heated seat pad cool completely.
3. Wipe the heated seat pad off with a slightly
damp cloth.
4. Allow all parts to dry completely afterwards.
6. Maintenance
Only use replacement fuses with the specified tech-
nical data.
There is a fuse in the 12V plug to protect the elec-
trical system of the vehicle. Check and replace the
fuse when the heated seat pad no longer works
(see Fig. D).
1. Unscrew the screw cap
from the 12V plug
2. Remove the plug tip
3. Remove the fuse .
9
4. Insert a new glass tube fuse (F5AL250V) onto
the spring .
8
5. Place the plug tip back on top of the new fuse.
6. Turn the screw cap clockwise to the 12V connec-
tor
Risk of short circuit!
Risk of damage!
Risk of fire and injury!
counter clockwise
11
.
7
.
10
7. Storage
- Allow the heated seat pad to cool completely.
- Store the heated seat pad in a clean, dry place.
- Keep the heated seat pad out of reach for
children.
- Avoid that the heated seat pad is kinked during
storage by heavy objects being placed on it.
- Do not weigh down the heated seat pad with
heavy objects.
8. Troubleshooting
For faults not listed here, please contact the
manufacturer.
Fault Possible cause Rectification
The heated The 12V
seat pad is
connector is not
not functio-
plugged into
ning.
the 12V vehicle
power connector.
There is no
voltage at the
12V vehicle
power socket.
The The 12V electrical
ignition is power socket
switched fitting is dirty.
on but the The contact
heated is therefore
seat pad interrupted
does not
The fuse of the
work.
12V plug has
blown.
The vehicle fuse
has blown
9. Technical data
Model:
Measurement seat part: ca. 43,5 x 48 cm
Measurement rear part: ca. 54,5 x 48 cm
Measurement total:
External material:
Internal material:
Temperature max.:
Power rating:
Power supply:
Plug the 12V plug into
the 12V vehicle power
socket correctly.
In many vehicles, the
ignition must be turned
on for the 12V vehicle
power socket to be
live.
Clean the 12V vehicle
power socket properly.
Replace the fuse of the
12V plug, see section
Maintenance.
Replace the vehicle
fuse for the 12V
vehicle power
connector. Please refer
to the handbook for
your vehicle.
17181 (CLIX I)
ca. 98 x 48 cm
Polyester
Polyurethane foam and Polyester
50° C
29,0 W (Low: 24 W,
High: 29 W)
12V
