5.6 Mounting installation
Note: The kit supplied in the package is designed for mounting on a solid wall. If mounted onto
other types of walls, you will need appropriate fixings (not supplied). Please make sure the wall is
safe to mount. We highly recommend to have the panel installed by a qualified electrician or
installer authorized by Sundirect.
1
Wall Installation Template
3
5
2
WALL
4
WALL
6
WALL
WALL
WALL
WALL
8
Wall mounting:
Step 1. Use the supplied
template to mark the
position of the holes on
the wall.
Step 2. Drill holes using
a 8mm drill.
Step 3. Insert the dowels
into the holes.
Step 4. Screw in the
supplied screws to the
wall.
Step 5. Mount the panel
on the screws.
Step 6. Move the panel
to the right or left side
until it's secured.
