5. Installation & Operation Guide
5.1 Description
This heater is equipped with our built-in thermostat receiver, the Lux receiver, located on the
backside of the panel. The heater works wirelessly with:
1). One master lighting and heating function controller (Smart Lux or Smart Lux Pro). Please note
that without the master controller, the heater won't work. Only one master controller can be paired
with one heater.
2). After pairing with the Smart Lux or Smart Lux Pro, you can still add extra light switches to control
your lighting system separately. You can add a maximum of 2 light switches to each heater and
control the lighting separately, but only after pairing with the master controller.
One master controller can control up to 10 heaters simultaneously.
On the right, see the drawing of the signal lights
and buttons of the Lux receiver.
Pair status signal light
1)
Heating status signal light
2)
"P" button
3)
Power switch
4)
The color of the pair status signal light indicates the following:
1. White: The heater is not paired with any controller.
2. Blue: The heater is paired with one master controller (Smart Lux or Smart Lux Pro).
3. Green: The heater is paired with one master controller and one light switch.
4. Red: The heater is paired with one master controller and 2 light switches. The heater is now fully
controlled and cannot add any more controllers.
5.2 Pairing the Master Controller to the Heater
1. Power on the heater. Ensure the pair status light is white. Double press the "P" button, and the
signal light will start flashing. The heater is now ready to be paired with the master controller.
2. Power off the master controller until the screen shows "OFF." Long press the "SET" button until
the screen shows the "Pair" sign.
3. The signal light on the receiver will stop flashing, indicating that the heater is successfully paired
with the master controller.
6
