12.2.1

New group

In the case of the first installation of the device, configure it as in chapter 12.2.3 Multi-pump settings. If, on the other
hand, the device has already been configured, the system will confirm the successful outcome of the procedure by
means of a pop-up message, and you will be able to return to the main menu
12.2.2

Add to a group

In the case of the first installation of the device, configure it as in chapter 12.2.3 Multi-pump settings. If, on the other
hand, the device has already been configured, the system will confirm the successful outcome of the procedure by
means of a pop-up message, and you will be able to return to the main menu.
12.2.3

Multi-pump settings

Operational pump

By operational pump we mean a pump that actively participates in pumping (not a reserve).
If the working mode has been set to Pressurisation, you will be asked to indicate whether the pump is acting as a reserve, the
number of pumps running at the same time, and their exchange time.
If the working mode has been set to Circulation, for twin circulators you will be asked to indicate the type of Interaction, while for
single circulators you will be asked to indicate whether the pump is acting as a reserve, the number of pumps running at the same
time, and their exchange time.
In the case of a first installation, once the procedure is complete, continue with the chapters 12.3.1 Setting Wizard – Single pump or
12.4.1 Setting Wizard – Single pump depending on your choice of mode.
Otherwise, if the pump has already been configured, you return to the Main Menu.

Connected pumps

By connected pump we mean one of the pumps belonging to the group after it has been correctly created.
If Pressurisation is set, refer to chapter 12.3.2 Setting Wizard – Pump groups.
If Circulation is set, refer to chapter 12.4.2 Setting Wizard – Pump groups.
ENGLISH
To create a new group, proceed as indicated by the system: press and hold the two
keys for 3 seconds to start searching for other devices to connect. An
association may not be possible because the device you are trying to associate is
already present in the maximum number or because the device to be associated is not
recognised. In the last case repeat the procedure by pressing the key
The search status for association remains active until the device to be associated is
detected (irrespective of the result); if no device can be seen within the space of 1
minute, the machine automatically leaves association status. You can exit search status
at any time by pressing
To speed up the procedure, a short-cut has been created that makes it
possible to put the pump in association from the main page by pressing
the keys
To add a device to an existing group, proceed as indicated by the system. Once the
option has been selected, the system automatically starts searching for an existing
group to which to connect the device. An association may not be possible because the
device to be associated is not recognised or because a group has not yet been created.
In the latter case, follow the system's instructions for creating a new group, see chapter
12.2.1 New group.
The search status for association remains active until the device to be associated is
detected (irrespective of the result); if no device can be seen within the space of 1
minute, the machine automatically leaves association status. You can exit search status
at any time by pressing
69
which automatically cancels the procedure.
which automatically cancels the procedure.
.
