ENGLISH
3. ASSEMBLING THE APPLIANCE
To hang the fan on the wall, follow the instructions below:
1. First, you need to drill 2 holes (approximately Φ 5 mm) where you want to place the fan.
NOTE: the distance between the two holes is determined by the distance between the holes at
the back of the fan.
2. Insert the two expansion plugs into each hole and then insert the locking screws into the
expansion plugs. The screws must leave a certain space for hanging the fan.
3. Finally, mount the fan on the wall, aligning the holes at the back with the screws.
NOTE: each package includes two screws and two expansion plugs.
4. OPERATION
Control panel. Fig. 2
1. Natural mode indicator light
2. Sleep mode indicator light
3. Oscillation indicator light
4. Oscillation button
5. Timer button
6. Speed button
7. Power button
8. High speed indicator light
9. Medium speed indicator light
10. Low speed indicator light
NOTE: make sure that the voltage used corresponds to the voltage indicated.
1. Plug the cable into the mains socket.
Press the button to turn the appliance on or off .
2.
3. Press the button to select between low, medium, or high speed. Once selected, the
corresponding indicator light will light up.
4. Press the button to set the timer. Each time you press it, the time will increase by
half an hour. The minimum operating time you can select is half an hour; the maximum
operating time is 8 hours.
5. Press to activate/deactivate the oscillation function. Once selected, the corresponding
indicator light will light up.
36
ENERGYSILENCE 4500 POWER WALL CONTROL
ENERGYSILENCE 4500 POWER WALL CONTROL BLACK
Remote control. Fig. 3
1. Timer button
2. Oscillation button
Off button
3.
4. Mode button
5. On/Speed button
: it is used to switch off the fan.
: it is used to switch on the fan and select the speed (low, medium, or high).
: it is used to set the timer. Each time you press it, the time will increase by half an hour.
The minimum operating time you can select is half an hour; the maximum operating time is 8
hours.
: it is used to activate/deactivate the oscillation function.
: it is used to select the mode (Sleep, Natural or Normal).
5. CLEANING AND MAINTENANCE
- Do not touch the blades with your hands or any object.
- Do not pull the cable sharply. If damaged, it must be repaired by a qualifi ed electrician.
Cleaning
1. Unplug the cord from the power supply.
2. Remove the grille and blades carefully.
3. Do not drop the blades.
Then use a soft, soapy cloth to clean the stains.
4.
5. Then, wipe it with a dry cloth.
NOTE: never use polishes or corrosive liquids that could damage the paint or the fan structure.
6. When you have fi nished cleaning, replace the blades and grille.
6. TECHNICAL SPECIFICATIONS
Product reference: 08349 / 04604
Product:
EnergySilence 4500 Power Wall Control
EnergySilence 4500 Power Wall Control Black
Voltage: 220-240 V
Frequency: 50 Hz
Power: 50 W
ENGLISH
ENERGYSILENCE 4500 POWER WALL CONTROL
ENERGYSILENCE 4500 POWER WALL CONTROL BLACK
