PCI 5DC IW / PCI 6DC IW / QCI 6DC IW
Product Feature Identification
PCI 6DC IW
PCI 5DC IW
QCI 6DC IW
Mounting Frame
Speaker Assembly
Speaker Assembly
Mounting Frame
Connector to
speaker assembly
Magnets for Grille
Slots for
mounting tabs
Quick Start Guide
Crossover PCB
(Note that this illustration may
Mounting
not represent the actual PCB)
Fasteners
(X2)
Connector to
mounting frame
HF Switch
(not on the
QCI 6DC IW)
Dual Concentric
Driver
Mounting tabs
Mounting clamps
Speaker wire
terminals
