Operating Instructions
Operation
5 Operation
Caution
!
!
The tyre pressure controller is not
suitable to fill bicycle tyres fitted with
normal bicycle valves and adapter.
The tyres may be overfilled !
Set required tyre pressure via +/- keys

„"
Press the button to acknowledge

the setpoint value.
Connect the hose with the tyre valve – the

filling process will start automatically.
A signal will sounded when the set-

point value is made. The process will be
repeated automatically for the following
tyres.
In case of completely deflated tyres, press the
„ " button a second time.
5.1 Operation Additional
Function
The 4 button on the AirMaster Com-
th
pact offers an additional function.
The available additional function is
specified by configuration with the DIP
switch.
5.2 Additional FunctionPressure
Units
Pressing the 4 button toggles the unit
th
of pressure between [bar] and [psi].
This function is active if DIP switch 5 is
set to "OFF" position.
5.3 Additional FunctionAdditional
Pressure (Overpressure)
Before inflating a tire, additional pres
sure can be entered.During the first
step, the compressed air regulator
inflates to set pressure + additional
pressure(setting pressure) and
during the 2 step, the set pressure is
nd
adjusted. The entire process runs auto
matically, without the operator interven
ing. This function is active if DIP switch
5 is set to "ON" position.
5.4 OverPresSure input
When youp press the 4th button,
„OPS" is displayed, followed by
the last selected overpressure.
Press „+" / „ - " to set the new
overpressure and „ ok" to confirm.
The new overpressure applies to each
subsequent fill operation. If an
overpressure of 0.00 is entered, the
function is disabled and air pressure
regulation takes place in a single step
(single-stage air perssure regulator).
