15 CIRCUIT DIAGRAM
• MINI TOUCH
Drain clamp
Angle Valve
Prefilter
• FLEXIBLE TOUCH
Sensor
Water tank
Sensor
Y O U R W A T E R B A R
Flushing valve
TDS
sensor
Inlet valve
Flushing Valve
TDS
sensor
Pump
Aflter-filter
UV
Filtered
Water
Water level gauge
After-filter
UV
Filtered
water
Water level gauge
Temperature
sensor
Pump Water
outlet
Heating coil
Temperature
sensor
Pump Water
outlet
Heating coil
