M A N U A L - M I N I T O U C H & F L E X I B L E T O U C H
Continuation
|
7
INITIAL OPERATION - MINI TOUCH
5
7
• STEP III
• The next step is to insert the supplied PREFILTER (9) between the angle stop valve and the
appliance. To do so, simply split the blue hose under the sink at any position and place
the pre-filter in between. Please pay attention to the direction of the arrow.
• STEP IV
• Connect the two hoses to the appliance. To do so, first pull out the two protective nubs
on "IN" and "OUT" (press the safety ring and pull out the protective nubs). Then insert the
hose from the angle stop valve into the "IN" connection and the hose coming from the
drain clamp into the "OUT" connection. Pull the hoses several times to ensure that both
hoses are firmly seated in their connections.
Y O U R W A T E R B A R
7.
9
6
8
· 2 6 ·
