M A N U A L - M I N I T O U C H & F L E X I B L E T O U C H
|
10
CHILDPROOF LOCK
• LIGHT INDICATOR STATUS
• If the childproof lock is unlocked, the indicator is off. In standby mode, it lights up dim-
med at 50 % brightness.
• NOTES
• If you want to withdraw warm/hot (BABY, TEA, HOT) water, the lock must be released. The
lock is released by briefly pressing the symbol once for approx. 3 seconds. (The childproof
lock is not activated for ROOM water).
• After water has been withdrawn, the childproof lock is automatically reactivated after
approx. 60 seconds. If you want to activate the childproof lock yourself, press the symbol
again for approx. 3 seconds after having taken the water. That way, you activate the child-
proof lock yourself (i.e., press and hold the childproof lock button for approx. 3 seconds to
cancel or set the childproof lock function).
• If BABY, TEA, or HOT is pressed without first unlocking, the childproof lock button flashes
once to prompt unlocking.
• If the childproof lock is pressed and held and you hear a beep twice, the childproof lock is
completely deactivated.
|
11
TECHNICAL SPECIFICATIONS
SPEZIFIKATION
Electrical parameters
Heating system
Consumption
Output
Filtration
Volume
Dimensions
Weight
Y O U R W A T E R B A R
UNIT
Voltage / Frequency
Wattage
Wattage
Power consumption
(standby mode)
Filtration volume
Installed filters
Clean water tank
Water tank
Length / width / height 300 x 183 x 388 mm
net weight
MINI TOUCH
220 V - 240 V / 50Hz
2250 W
2180 W
0,0 - 0,1 kW-h/24 h
ca. 10-15 l / h
Composite, After-filter,
RO Membrane, UV-Lamp
2,5 litres
-
11,81 x 7,21 x 15,28 inch
6,5 kg
FLEXIBLE TOUCH
220 V - 240 V / 50Hz
2250 W
2180 W
0,0 - 0,1 kW-h/24 h
ca. 10-15 l / h
Composite, After-filter,
RO Membrane, UV-Lamp
1,5 litres
5,0 litres
405 x 183 x 388 mm
15,95 x 7,21 x 15,28 inch
7,1 kg
· 3 0 ·
