FILTER MATERIAL
Either Filterballs or sand can be used
as a filter material.
Filter sand: Sand is historically the most common
filter material. And with good reason. The natural
material picks up particles down to 40 micron. On
the other hand, sand, and especially wet sand, is
mega heavy. Therefore, it is recommended that
the filter system is located in its intended position
before the tank is filled with sand. Sand also
requires ongoing backwashing, a minimum of 2-4
times per month, in order to clean the sand. This
means that you use more water when you choose
sand as a filter material. In a pool with 30-40,000
litres of water, between 180 and 240 litres of
water is used per backwash.
Filter glass: There is a big difference when
the choice is between filter sand and filterglass
as filter media. Compared to filter sand, filter
glass (NatureWorks) saves up to 60% in
power consumption, up to 75% in water saving
beacause the necessity of back washing is less
and cleans particles down to 10 μm (microns)
compared to filter sands 50 μm (microns). The
ilter sand neeeds to be changed during pre-
season before the sand filter is used again. This
is not needed with filter glass, the same filter
glass can be used for many years.
Powerful pump and large filter tank
The system comes with a powerful pump that is
proportionate in capacity to the filter tank size and
the pool volume specified in the specifications
below. The pump must have enough power to
be able to circulate all the pool water 5 times
a day - through the filter material. As a general
rule, the cleaning capacity of the pump must as a
minimum be the pool water volume divided by 5.
The pump is suitable for use in salt water.
Fitting and hose connection
The system can be mounted directly on all pools
with a regular pump outlet, and is suitable for use
with standard hoses of Ø50 mm. Filter material
and hoses for pools are not included.
2
Specifications
Operation over pressure
Cord length including plug
Max. ambient temperature
Min. ambient temperature
Maximum pool size in litres
Pump power
Pumpe Flow Rate
Qmax l/min
Hmax m
Flow Rate Filtermateriale
Tank volumen
Volumen Filtermateriale
El-installation
Pressure gauge
Pre-filter
Filter tank size mm
Power
El-installation
Hose connection mm
Pump type
MV-1042-06-2022 . © Alle rettigheder forbeholdes Swim & Fun A/S
Filter
Sand
Glass
1.5 bar
1.5 metres
35 ºC
-4 ºC
60.000 liter
600 W
17.000 l/h
-
10
12.180 l/t -
75 L
75 kg 60 kg
Automatisk differential
switch (30 mA)
Yes
Yes
Ø 500
230V/50 Hz
Automatic differential
switch (30 mA)
Ø32/38/50
Self-priming
