SOMFY Amy 1 io Anleitung Seite 9

Amy 1 io
1] Drill 2 horizontal holes through the indicated drill marks on each side inside
the circular back cover.
2] Fix the circular back cover using screws appropriate for hole size and wall
type, following the orientation indicated inside the circular back cover.
NOTICE
Make sure Amy 1 io is switched on before clipping the module (refer to Switching
on Amy 1 io).
3] Clip the Amy 1 io module onto the circular back cover. Press firmly on the
front of the module, on the right and left near the my button as close as
possible to the translucent circle without pressing on the edges of the module
(to avoid unwanted radio transmission), until it clicks into place.
2.6.Use as a remote control
NOTICE
Amy 1 io can be used as a remote control without being wall-mounted. However, care must be taken to ensure that
the circular back cover is securely attached to Amy 1 io module to protect the back access from any risk of damage
and avoid accidental activation.
1] Take the circular back cover and clip the Amy 1 io module onto it, following
the orientation indicated inside the circular back cover. Press firmly on the
front of the module, on the right and left near the my button as close as
possible to the translucent circle without pressing on the edges of the module
(to avoid unwanted radio transmission), until it clicks into place.
2] Amy 1 io can therefore be used as a remote control that can be put down and
moved around.
2.7.Tips and advice on installation
2.7.1.Questions about the product?
Observations
The selected motorised product does not react
at all when a button on Amy 1 io is pressed (No
LED reaction when pressing the buttons).
The selected motorised product does not react
at all when a button on Amy 1 io is pressed (No
LED reaction in the front when pressing a button
AND in the back when pressing the On/Off
button).
The selected motorised product does not react
at all when a button on Amy 1 io is pressed but
the LED lights up.
The selected motorised product does not react
at all when a button on Amy 1 io is pressed but
the LED lights up and the control point is paired
with this motorised product.
The motorised product does not react when the
indoor temperature rises (the scenes
programmed in TaHoma in the event of a
change in indoor temperature do not launch).
©
Copyright 2024 SOMFY ACTIVITES SA. All rights reserved.
Possible causes
Amy 1 io is switched off, the front
panel buttons (Up, Stop/my, Down)
are deactivated.
The control point battery is low.
The control point is not paired with
this motorised product.
External radio equipment is
interfering with the radio reception.
The temperature feedback to
TaHoma is deactivated on Amy 1
io.
1]
2]
3]
Solutions
Switch it on to activate the buttons
(refer to Switching on Amy 1 io).
Change control point battery as
required (refer to Replacing the
battery).
Refer to Adding/Deleting Amy 1
io.
Turn off any nearby radio
equipment.
Check sensor status on TaHoma
application and refer to Use with
TaHoma if necessary.
EN
9
