Flash energy output adjustment

> When a group is selected you can adjust the
energy output of the light assigned to this
group by pressing +/- buttons.
> Energy output can be adjusted in 0.1 stop
increments but If you need to speed up the
process hold the the +/- buttons and power
will jump one stop up or down.
>
Trigger power output scale starts from 1.0 and
ends at 10.0. It's made that way to be compa-
tible with other/future GlareOne lights but in
case of Vega 400 studio flash usable range of
the scale will be within 4.0 - 9.0

Triggering flash

> When Flash RC is connected to the camera and properly configured to
communicate with the lights, flash can be triggered just by pressing the
camera shutter button. Flash will be triggered and synchronized with
the exposure.
>
Some cameras may offer first and second curtain flash synchronization.
More information on this topic can be found in their manuals.

Test flash

>
You can manually trigger the test flash of your
lights by pressing the Test button. All flashes
will be triggered in the selected channel with
the set flash energy.
