Nice MyBell Anweisungen Und Warnhinweise Seite 5

3. Fill the gap between the wall and the flush-mounting box with cement or non-corrosive adhesive.
4. Brush the outer surface of the gap with the same decorative materials as the surrounding walls.
5. Wait for the cement to dry before proceeding to the next step.
6. Use six M4X8 crosshead screws to fix the flush-mounting bracket on the box.
3.3 - Main unit installation
1. Connect the wires to the terminal blocks with flat-head screwdriver. For more information, see Figure 2.
Note
Strip the wires by removing the plastic sheathing, and make sure the exposed wire ends are from 4 to 7 mm long.
2. Insert terminal blocks, Ethernet cable, and Micro SD Card to the corresponding interface of device.
3. Select and press an appropriate rubber plug into the corresponding groove of device.
4. Organize cables and use four M3X5 crosshead screws to secure wiring cover to the device.
3.4 - Device mounting
1. Insert plate removal key into the small hole of the card reader plate touch plate to pull it out.
2. Hang the slots on the back upper part of the device into the corresponding hooks of the mounting box. Snap the device into place and
press it down.
3. Fix two M3X9.5 torx head screws into the holes.
4. Press the card reader touch plate back into its original position. Make sure the card reader touch plate is installed in the right direction.
5. Installation is completed, please remove the protective film.
4
DEVICE TESTING
Verify the device status after installation:
1. Network: Press *2396# to access settings page. Then press 1 to check the device IP address and network status on System Information
page. Network is working properly if the IP address is obtained.
2. Intercom: Dial the IP or SIP number and press the Dial key to make a call. Or, press APT number to call. The call configuration is correct if
the call is successful.
3. Access Control: Use pre-configured PIN code, RF card, and face to unlock door.
5
REGULATIONS
5.1 - Warranty
We warrant this product to be free from defects in material and workmanship under normal and proper use for two years from the purchase
date of the original purchaser. We will, at its option, either repair or replace any part of the products that prove defective due to improper wor-
kmanship or materials. THIS LIMITED WARRANTY DOES NOT COVER ANY DAMAGE TO THIS PRODUCT THAT RESULTS FROM IMPROPER
INSTALLATION, ACCIDENT, ABUSE, MISUSE, NATURAL DISASTER, INSUFFICIENT OR EXCESSIVE ELECTRICAL SUPPLY, ABNORMALME-
CHANICAL OR ENVIRONMENTAL CONDITIONS, OR ANY UNAUTHORIZED DISASSEMBLY, REPAIR OR MODIFICATION. This limited warranty
shall not apply if: (i) the product was not used in accordance with any accompanying instructions, or (ii) the product was not used for its intended
function. This limited warranty also does not apply to any product on which the original identification information has been altered, obliterated
or removed, that has not been handled or packaged correctly, that has been sold as second-hand or that has been resold contrary to Country
and other applicable export regulations.
5.2 - Declaration of conformity
Hereby, Nice S.p.A.declares that MyBell IP Keypad Station is in compliance with the essential requirements and other relevant
provisions of Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address:
http://www.niceforyou.com/en/support
5.3 - WEEE Directive Compliance
Device labelled with this symbol should not be disposed with other household wastes. It shall be handed over to the applicable
collection point for the recycling of waste electrical and electronic equipment.
5.4 - Full instruction manual
For the full instruction manual and technical specification please visit our website:
https://www.niceforyou.com/en/professional-area/download?term=IS0928A00&cerca=SearchDownload&v=7
5
