Radar Sensor
Loudspeaker
3
INSTALLATION
Tools needed and not included in the box:
• Cat Ethernet Cable
• Crosshead Screwdriver
• Electric Drill
We recommend using PoE+ or 12VDC 2A power adapter to power on device.
Please follow the American wire gauge (AWG) sizes and properties table below to install device:
Table A2 - MyBell IP Keypad Station - AWG
Property
Power Supply
AWG
Resistance (ohm/km)
Cross-sectional Area (mm²)
Wire Length (m)
Wire Length (m)
(external power supply)
Microphone
Figure 1: MyBell Keypad station - overview
20
33.9
0.5189
≤30
≤20
Value
12 V DC 2 A
22 24
48.5 79.6
0.3247 0.2047
≤20 ≤15
≤15 ≤10
Infrared LED
Camera
Photosensitive Sensor
LCD
Numerical keypad
Card Reader
26
128
0.1281
-
-
