7.3.6_cHanGinG tHe Wallpaper

On the Home Screen, tap and hold the screen to show options
for the Wallpaper.

8_SPEcificationS

frequencies
Quad band
GSM/GPRS/EDGE
850/900/1800/1900 MHz
WCDMA/HSPA
900/2100 MHz
Dimension
weight: 206 g,
size: 124 x 68.5 x 24 mm
screen
3.2" (8.13 cm) RugDisplay-
Glass, rugged TFT-touch-
screen with a resolution of
320 x 480 pixel
cameras
5 MP rear camera
0.3 MP front camera
loudspeaker
amplified 3 watt, with 100 dB
Wireless technologies
Bluetooth®, Wi-Fi®, GPS, NFC
DiSPlay layout / inforMation
battery
2060 mAh, standby 300 hrs.,
talktime 2G/3G:
468 min./210 min.
memory
internal memory 4 GB ROM,
512 MB RAM, external
memory microSD up to 32 GB
processor
MT6572 (Dual Core 1.2 GHz)
temperature
operation range from
-20 °C to 60 °C
ip68
waterproof: 30 min. up
to 2 m, impervious to dust
and microparticles
mil-stD-810G
2 m drop-protection,
impervious to dust and
microparticles
inforMation

9_troublESHootinG

If problems occur when using the mobile, please try the
following tips. If the problem is not solved, please contact
your vendor or RugGear Europe GmbH directly.
tHe pHone cannot be poWereD on
the battery voltage is too low.
Please recharge the battery.
the power on key is not pressed long enough.
Please press power on key for more than three seconds.
the connection to the battery is bad.
Please assemble the battery again or clean the contact
points of the battery carefully.
the sim card has a failure.
Please check or replace the SIM card.
tHe pHone Has insufficient stanDby time
the battery performance is reduced because of the age
of the battery.
Please contact your vendor or RugGear Europe GmbH
for a replacement battery.
too many programs running.
Please reduce the number of running programme.
