English
PRODUCT SPECIFICATIONS
Model DXVCS002
Tank capacity 23 L**
Ef ciency 99.5%*
Hose 48mm x 2.1m
* Tested on sand, screws, wood chips and scraps of paper
with DXV30SA.
**Tank capacity refers to actual tank volume and does not re ect
capacity available during operation.
PACKAGE CONTENTS
The package contains:
1 48mm x 2.1m Hose (DXVA19-2504)
4 Caster
6 Screw ST4.8 x 16F
4 Screw ST3.9 x 16F
1 Instruction Manual
• Check for damage to the tool, parts or accessories
which may have occurred during transport.
• Take the time to thoroughly read and understand
this manual prior to operation.
DEFINITIONS: SAFETY GUIDELINES
The de nitions below describe the level of severity
for each signal word. Please read the manual and
pay attention to these symbols.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death
or serious injury.
WARNING: Indicates a potentially hazardous
situation which, if not avoided, could result in
death or serious injury.
CAUTION: Indicates a potentially hazardous
situation which, if not avoided, may result in
minor or moderate injury.
NOTICE: Indicates a practice not related to
personal injury which, if not avoided, may result
in property damage.
IMPORTANT SAFETY INSTRUCTIONS
WARNING: When using electric appliances,
always follow basic safety precautions to reduce
the risk of re, electric shock and personal injury,
including the following:
BEFORE USING THE APPLIANCE, READ AND
FOLLOW ALL INSTRUCTIONS.
• Do not allow the accessory to be used as a toy.
Pay close attention when the accessory is used
by or near children.
• Use this accessory ONLY as described in the
manual. Use only D WALT recommended
E
attachments.
• To reduce the risk of health hazards from vapors
or dust, do not use dust separator with toxic
materials. Do not use or store near hazardous
materials.
• To reduce the risk of injury from accidental starting,
always shut off vacuum and disconnect the power
plug from the wall outlet before connecting the
dust separator to the vacuum.
• Wood dust mixtures are highly ammable and can
be explosive.
• NEVER introduce sparks or sources of ignition
into collector.
• Do not use the accessory to pick up ammable or
combustible liquids, such as gasoline, or use in
areas where ammable or combustible liquids
are present.
CAUTION: The Appliance is not intended for use
by people (including children) with reduced physical,
sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Children should be supervised to ensure that they do
not play with the appliance.
THE DUST SEPARATOR IS MADE OF
STATIC DISSIPATING PLASTIC
INSTALLATION OF SEPARATOR TANK
(Fig. B)
1. Place separator
2 3
lid , ensuring that the ribs are aligned with
2 6
the slots.
2. With the lid in an upside down position, insert
provided screws(ST4.8 x 16F)
3. Use screwdriver (not included) to secure
and tighten the screws(ST4.8 x 16F)
NOTICE: The ribs on both sides of the separator
must be aligned with the two small slots in the
recess of the cover.
CASTER INSTALLATION (Fig. C)
1. Invert the dust tank
2 8 to the bottom of the dust tank and x them
with screws(ST3.9 x 16F)
2. Return dust tank
2 5
OPERATING INSTRUCTIONS (Fig. D)
WARNING: To reduce the chance of re
hazard, empty dust tank after each use.
The dust separator contains a lter feature. It has
the capability to inlet sawdust and other debris. It
can be used to inlet dust and debris out of garages
or off patios and driveways. Follow the steps below
to use the dust separator with dust tank.
1. Insert the vacuum's hose end into outlet of dust
separator, the hose should be snapped into place.
6
tank into the recess on the
.
2 9
.
2 9
and install the casters
2 5
.
2 10
assembly upright.
