This switch controls single-phase control circuit power to the machine and the DC power
supply for the microprocessor and its components. Setting this switch to during
operation stops the machine.
This signal is activated when operator attention is required, as when unloading is required
or certain errors occur. Pressing cancels the signal.
This button extinguishes the operator signal ( ). If the signal was programmed as part
of a formula, the formula resumes after this button is pressed. If an error caused to
illuminate, pressing after correcting the error will extinguish the signal. If was
illuminated when a valid formula was selected, the signal will terminate automatically
when the formula is started or the door is opened.
Setting the keyswitch to prevents programmed data from being changed and allows
normal machine operation. Setting the keyswitch to allows programming machine
operation and certain troubleshooting procedures.
This large red button in a yellow rectangle may appear in several locations on the machine.
It performs the same function as , but locks in the depressed position and must be
turned to release the button and close the circuit before operation can resume.
This button stops the machine immediately by opening the three-wire circuit. Emergency
Stop buttons perform the same function. Pull cords and kick plates, if the machine has
them, also perform the same function.
This button enables machine operation if certain safety considerations are met. When
operation is enabled, the machine will operate in manual or automatic mode.
This button starts machine operation.
