INSTALLATION •
INSTALLATION
Installation vertikal •
Installation vertical
* Muss separat bestellt werden
Must be ordered separately
Doit être commandé séparément
Moet afzonderlijk worden besteld
Montage Einstellwinkel •
DE
Montiere das Rücklicht in einem 90° Winkel zur Fahrbahn.
EN
Mount the tail light at a 90° angle to the road surface.
• INSTALLATION •
• Installation verticale •
Feste Montage •
Fixed mounting
Montage fixe •
Vaste montage
Seatpost clamp*
Art. No.: N-SPC-27.2-BLK
N-SPC-31.6-BLK
TL3 MINI
Art. No.: W-TL3M-S-V6-BLK
Mounting adjustment angle
INSTALLATIE
Installatie verticaal
• Angle de réglage du montage •
Bezugsachse parallel zur Fahrbahn
Reference axis parallel to the roadway
Fahrbahn •
Roadway
Axe de référence parallèle à la chaussée
Route •
Rijweg
Referentieas parallel aan de rijbaan
FR
Monte le feu arrière à un angle de 90° par rapport à la chaussée.
NL
Monteer het achterlicht in een hoek van 90° ten opzichte
van het wegdek.
Befestigungsgummi
Mounting rubber
La bande de fixation élastique
Bevestigingsrubber
Montage aanpassingshoek
12 • 13
