Operating Instructions
Evaluation Unit CES-A-.1B-01B-AS1
Mounting hooks
Bottom of
housing
33
39
Fig. 2: Dimension drawing for CES...AS1
Evaluation unit
Read head
CES-A-LNA-SC
077715
CES-A-LMN-SC
077790
CES-A-LQA-SC
095650
CKS-A-L1B-SC
CES-A-F1B-01B-AS1
113130
094230
CEM-A-LE05K-S2
094800
CES-A-V1B-01B-AS1
CEM-A-LE05R-S2
096631
095792
CEM-A-LH10K-S3
095170
CEM-A-LH10R-S3
095793
CET1-AX
All items
Key to symbols
Table 3: Combination options
Mounting straps
max. 39
60
28,5
4,5
Fixing screw
Actuator
Combination possible
Combination possible, guard locking for process protection
Combination possible, guard locking for personnel protection
Combination not permissible
Top of housing
with evaluation
electronics
-20
Labeling clips
With evaluation unit CES-A-.1B-01B-AS1 in conjunction with read
head CES-A-LNA...AS1 or CES-A-LNA-SC and actuator CES-A-BBA
on surface mounting of the read head and the actuator. In case
of flush installation, the operating distances change as a function
of the installation depth and the guard material.
For a side approach direction for the actuator and read head, a
minimum distance of s = 3 mm must be maintained so that the
actuating range of the side lobes is not entered.
Fig. 3: Typical actuating range
Important!
We recommend the use of CES-A-LNA-SC read
f
heads. If other read heads are used, other ac-
tuating ranges are applicable. Please contact
our support team for more detailed information.
The CEM guard locking devices do not fea-
f
ture guard lock monitoring according to
EN ISO 14119 and therefore must be used only
as guard locking devices for process protection.
If the CKS key adapter is used in combination
f
with this evaluation unit, the LED of the CKS
key adapter cannot be controlled.
8
m
Output stage
Actuator
s
ON
Read head
Release
OFF
20
distance
OFF
OFF
15
Hysteresis
Operating
distance S
a0
10
Side
Side
lobe
lobe
5
N
ON
-15
-10
-5
0
5
10
15
Centre offset m [mm]
Hysteresis
S
Distance
a0
s
N
20
