en
WS-PRIMER
DESCRIPTION OF THE PRODUCT
ANEST IWATA spray guns are designed according to the most innovative Spray-Painting Technologies and they are
specifically developed for the atomization and application of new generations of technologically advanced and eco-
friendly paint products. The WS-Primer gravity feed spray gun has been designed specifically for the most important
Primer applications and it is available in 2 different workflow versions: Wet-on-Wet and Filler.
1. IMPORTANT INFORMATION
This instruction manual is an integral part of gravity spray gun and must to be read carefully
before starting ANY ACTIVITY involving the use, adjustment and maintenance of the equipment,
including its handling. This manual must be stored in a safe place for any future reference. Be sure
to observe warnings and cautions in this instruction manual. If not, it can cause paint ejection and
serious bodily injury by drawing organic solvent.
2. SAFETY SYMBOLS
ALWAYS OBSERVE WARNINGS AND CAUTIONS IN THIS MANUAL
SYMBOL WARNING
WARNING
CAUTION
IMPORTANT
3. COMPLIANCE TO STANDARD OF SPRAY GUN
ANEST IWATA Spray Guns comply with 2014/34/EU Directive relating to equipment and protective systems intended
for use in explosive potentially atmospheres.
COMPLETE COMPLIANCE MARKING:
ABBREVIATE MARKING
ON THE SPRAY GUN:
4. TECHNICAL SPECIFICATIONS
Max. working air pressure:
Weight g (lbs): (without cup)
Noise level (LAeqT)*:
Air Connection:
Fluid Connection:
Max. Temperature range:
* Measuring point: 1m backwards from gun, 1.6 m height.
5. TECHNICAL DATA
TYPE of
APPLICATION
m o d e l na m e
WET on WET
FILLER
2
WET on WET & FILLER
HAZARD LEVEL
POTENTIALLY
HAZARDOUS
SITUATION
II 2 G Ex h IIB T6 Gb X +5°C ≤ Ta ≤ + 40°C
II 2 G Ex h X
ø m m ( i n) a i r c a p b a
1. 2 ( 0. 0 47)
1. 3 ( 0 . 0 51)
1. 4 ( 0 . 0 55)
1. 4 ( 0 . 0 55)
1. 6 ( 0 . 0 62)
1. 8 ( 0 . 0 70)
-
G R A V I T Y S P R A Y G U N S
DEATH OR SERIOUS INJURY
MINOR TO MODERATE INJURY
PROPERTY DAMAGE
II 2 G Ex h X
II 2 G Ex h X
10 bar (145 PSI)
380 (0.84)
85 dB(A)
G1/4" M
G1/4" F
Atmosphere 5 ~ 40 °C / Air-Fluid 5 ~ 43 °C
r ( p s i ) N l / m i n ( c f m ) m m
150 ( 5 . 90)
180 ( 7 . 08)
190 ( 7 . 48)
2. 0 370
( 2 9) ( 1 3. 0 6)
190 ( 7 . 48)
210 ( 8 . 26)
235 ( 9 . 25)
CONSEQUENCE
FLUID NOZZLE_NEEDLE SET
COMBINATION
Fluid Nozzle Fluid Needle
( i n)
A I W S P 12 10 - 12 W S P
A I W S P 13
13 - 18 W S P
A I W S P 14
A I W S P 14
A I W S P 16 13 - 18 W S P
A I W S P 18
