• Setthe ON/OFF s witch on the remotecontrol(2C) to "ON". T hepowerLED
lights up on the remote control (4A).
• Set the ON/OFF switch on the model(1B)
The ON/OFF switch on the model and the remote control must be set to OFFafter
use. Otherwise,a drive command can accidentallybe triggered, causingthe vehicle
to drive away on its own, which can lead to conside able damage.
The correct trim is a basicrequirement for fault-free driving behaviourfrom the
vehicle. Adjusting the trim is easy,but it requiresa little patience and a feel for it.
Pleasefollow the following instructions precisely:
If the vehicle pulls to the left or right while driving without steering...
use the trim lever
direction. The trim ever can be found on the underside of the vehicle (cf. 5).
6A To drive forwards, pull the leve for forwa d and eversetravel (2A) with the left
index finger.
Todrive in reverse, p ushthe leverfor forwardand reversetravel(2A) forwards
6B
with the left index finger.
6CTo drive along a left curve, turn the steeringwheel
6D Todrive along a right curve,turn the steering wheel (2D) to the right.
4 START PREPARATION
5 STEERING TRIM ADJUSTMENT
to correctthe wheel alignmentby turning it in the opposite
6 VEHICLE CONTROL
(4B)
(20)
to the left (top view).
(2B)
11
