HF2403_HF2403e
EN
Turning the phone on/off
To turn the phone on/off press and hold the Red handset button.
If directly after turning the phone on you will see the code request,
(in form of "****") type the code and press Menu button.
Inserting a SIM card, memory card, and the battery
If the phone is switched on - switch it off. Unscrew the screws
securing the battery compartment cover and remove it. Insert the
SIM card/s - Card/s is/are supposed to be placed with its gold
contacts facing down, the way in which the slot is embossed.
Insert the memory card. To open the flip of the card reader slide
it delicately aside. Insert the microSD memory card with its gold
contacts facing down, the way in which the slot is embossed.
Close the flap by sliding it slightly in the opposite direction than
when opening. Insert the battery so that its gold contacts touch
the tripple connector in the phone bay. Make sure the flap and the
rubber are intact and not damaged. Replace and gently press the
flap and tighten the retaining screws.
Charging the phone
Connect the USB-C charger to the charger connector on your
phone, then connect the charger plug into the power grid.
*Attention: Improper connection of the charger can cause serious
damage to the phone. Damages caused by an improper use of the
phone are not covered by the warranty. The icon
(or similar)
will appear during charging and when the battery is fully charged.
When charging is complete unplug the charger from the power
outlet. Unplug the cable from the socket on the phone.
29
