ENGLISH
3. ASSEMBLY
1. Insert the hook as shown in figure 2.
2. Insert the cleaning accessory you wish to use into the hose as shown in figure 3.
3. Insert the hose hook as shown in figure 4.
4. Insert the battery as shown in figure 5.
Filling up the water tank
1. Remove the clean water tank from the main body of the device, to do so slide the clean
water release tab and remove the tank in the direction of the arrows shown in figure 6.
2. Turn the clean-water tank, loosen the cap, and fill the tank with clean water. The maximum
water capacity is marked on the tank as "MAX", do not exceed it under any circumstances.
Fig. 7-8
3. Screw the cap and install the clean-water tank back into the main body. Fig. 9-10
Note
- After filling the tank with water, you must tighten the cap correctly to avoid leakage.
- You can add low-foam detergent to the clean-water tank.
- After using your device, you must empty the remaining water in the clean-water tank to
avoid leakage and mould formation.
- Do not shake the clean-water tank during installation, as it could cause water leakage.
Upholstery cleaning accessory
Press the button under the head to switch between the brush head and the plastic head.
4. OPERATION
1. Read the label of the fabric you wish to clean to check that it is suitable for this cleaning
process.
2. Press the power button to turn the device on. Fig. 11
3. Press and hold the water release button to spray clean water. Spray clean water on the dirt
to bring it to the surface. Fig. 12
4. Press the suction inlet on the dirt to bring water and dirt to the surface and vacuum them.
Fig. 13
5. Stop spraying clean water and vacuum the waste water. After using the appliance, allow
the surface to dry before using it again.
6. Switch off the device by pressing the power button.
7. Empty the clean and wastewater from the tanks and clean the waste-water tank.
8. Connect the self-cleaning head and activate it for 30 seconds. Fig. 15
62
CONGA CARPET&SPOT CLEAN INFINITY
Note
- Do not spray water continuously over the same spot.
- Switch off the appliance before unplugging it.
- After using the device, hang and wind the power cord in the power cord hook.
- To know the detergent quantity and use, carefully read the manufacturer instructions.
- Stop using the device when the water or foam in the waste-water tank reaches the
maximum water level and clean the waste-water tank. Otherwise, water may enter the
machine.
5. CLEANING AND MAINTENANCE
Note
- Switch off the appliance before cleaning it.
- Do not wet the device to avoid the risk of electric shock.
- Do not use detergents, thinners, benzene, or other chemical agents to clean the device.
- After every use, you must remove and clean the waste-water tank, the clean-water tank,
and the suction nozzle (A/B) to prevent humidity and dirt remains from emitting bad
odours.
Cleaning the main body
- The most common dirt can be cleaned with a slightly damp cloth.
- The most stubborn dirt can be cleaned with a cloth slightly soaked in detergent and then
a cloth slightly soaked in water.
Cleaning the waste-water tank
1. When the wastewater reaches the maximum level, stop using the appliance and remove
the waste-water tank.
2. To do so, slide the waste-water tank release tab and remove it in the direction of the arrow
shown in Figure 16.
3. Remove the upper cover of the waste-water tank. Fig. 17
4. Remove the buoy as shown in figure 18, drain the water and clean the buoy and the inside
of the tank by hand.
5. Make sure all parts and components are dry before reinstalling and replace the cover. Fig.
19
6. Place the waste-water tank in the main body of the device.
Note
- Do not lean or shake the waste-water tank when transporting or assembling it; otherwise,
wastewater will easily leak.
- We recommend you empty the wastewater before it exceeds the maximum level on the
ENGLISH
