Operating Mode DMX:
Connect the DMX input of your device to the DMX output of your DMX controller, your DMX
software or the DMX output of a device already in your DMX chain. Always use DMX cable
with a 110 Ohm impedance for this connection. Address the device according to your DMX
configuration. The device has a DMX mode with 7 channels, which are based on the following
functions:
7 Channel Mode:
Channel Function
1 Strobe program
2 Red
3
Green
4
Blue
5 Strobe
6 Motor
7 Programs
Static, Auto or Sound mode:
The device contains automatic programs that run according to predefined patterns (auto) or are
activated via the built-in microphone to match the music (sound). The selection of the respective
mode is made via the menu directly on the device.
Operating mode master/slave:
If you connect several devices of the same type via DMX, they can be controlled simultaneously via
the master device. To do this, set the desired function on the first device in the chain; the other de-
vices in the series must now be set as „slaves". Now the first device in the chain gives the function
to all other devices and all devices run simultaneously.
Value Description
001-005 Open
006-255 Slow to fast
001-255 Dark to light
001-255 Dark to light
001-255 Dark to light
001-255 Slow to fast
001-005 Off
006-127 Motor forward
128-255 Motor backward
001-005 Program CH1-5
006-250 Automatic program
251-255 Sound to Light
