you have a 24-pin connection, place the remaining 4 pins in the correct position
before you plug the connector into the socket. If you have a motherboard with a
20-pin connector, fold the additional 4 pins to one side.
• Now plug the 12V-P4 or P8 connector for the CPU into the socket provided on
the motherboard.
5. SAFETY
All be quiet! power supplies have numerous safety functions. They are designed to
protect the power supply and the components connected to it against damage. If
one of these safeguards is triggered, the system will reboot or power off in most
cases. If this happens, you should immediately check the PC for errors.
For more info on troubleshooting
The be quiet! Pure Power 11 series has the following safety functions:
OCP (Over current
If the load on the individual circuits exceeds the specified limit, the power supply
is automatically switched off.
UVP (Undervoltage
This safeguard is triggered if the voltage on the circuits drops below a certain limit.
The power supply is automatically
OVP (Overvoltage
The overvoltage safeguard is triggered if the voltage in the circuits is too high; the
power supply is deactivated.
SCP (Short circuit
The fuse protecting
defects of the power supply and the components connected to it.
OTP (Temperature
In the case of excessive heat build-up in the power supply, the power supply
immediately and automatically
has cooled down. Please ensure that the PC has sufficient cooling.
OPP (overload protection)
This safeguard is triggered
the specified maximum load. This can happen if the output of power supply is
insufficient for the system (incorrectly dimensioned).
FUNCTIONS
see the "Troubleshooting"
protection)
protection)
switched off in this case.
protection)
safeguard)
the power supply's
safeguard)
switches off. You cannot switch it back on until it
if the total output
secondary circuits
of the power supply exceeds
chapter.
prevents physical
