Vankyo Performance V700G Benutzerhandbuch Seite 6

Device Overview
Lens
OK
Back
Left
•
1. Power: Press to turn on, enter standby mode, or wake up the
projector. Press and hold for 3 seconds to power off completely.
•
2. Google Assistant: Press and hold to activate Google Assistant.
Speak into the remote to search or issue commands.
•
3. User Profile: Press to open the profile page.
•
4. OK: Press to confirm selections or to pause and resume playback.
•
5. Back: Press to go back to the previous screen.
•
6. Focus Adjustment: Press to adjust the focus of the projected
image.
•
7. Mute: Press to mute or unmute the sound.
•
8. Streaming Apps: Jump directly to video streaming pages.
•
9. Indicator Light: Displays the status of the remote.
•
10. Input Source: Press to select from available input sources.
Up
Adjustment
IR Receiver
Sensor
Down
USB
Power Input
Air Inlet
Up
Power Button
Right
6
HD
IR Receiver
Audio Out
Speaker
Speaker
Air Outlet
