INSTALLATION INSTRUCTION
• DO NOT USE IN AREAS WITH LIMITED VENTILATION OR OUTSIDE THE RATED AMBIENT TEMPERATUR-
ERANGE. *CONNECT WITH WATERPROOF CABLE HOUSE ONLY.
*ENSURE ELECTRICITY IS SWITCH OFF BEFORE INSTALLATION.
• Please do not mount to a surface that is prone to vibrations.*
• Remove the screw which is for mounting the bracket for the fixture. Remove the bracket.
• Mark the hole position for fixing bracket onto the wall. Drill onto the wall at the marked
positions (screw not supplied).
• Mount the bracket back to the fixture. Adjust the floodlight to desired position and tighten the screw of
fixing bracket.
• Connect your mains cable with input lead of our product through the waterproof junction box(not includ-
ed).
• Switch on the power and test if the light is working properly.
• Adjust the irradiation angle according to the condition of usage.
FUNCTION
• LUX Setting: Can identify day and night. The consumer can adjust the work ambient light. It can work
during the daytime and at night when adjusted to the "sun" position (max). It can work in the ambient light
less than 5LUX when it is adjusted on the "moon" position (min). As for the adjustment pattern, please refer
to the testing pattern.
• SENS adjustable: For low sensitivity with 2m for detection distance set the SENS knob to (-); for High
sensitivity with 8m set the knob to (+).
• Time-Delay is added continually: When it receives the second induction signals a er the first induction, it
will compute time once more on the basis of the first time-delay rest. Time-Delay is adjustable. It can be set
according to the consumer's desire. The minimumtime is 12s. The maximum is 6 min.
Manual Override:
1. To override the automatic mode, the sensor must be switched ON in the automatic mode. Now turn the
wall switch OFF and switch powern ON within 2 seconds. The floodlight will flash confirming the light has
been switched to constant light mode.The sensor will now hold your light ON continuously just likes a normal
light.
2. To switch the floodlight into automatic mode, turn your wall switch OFF, then switch ON a er 10sec-
onds.The floodlight will flash confirming the light has been switched to automatic light mode.
TEST
• Turn the SENS knob clockwise on the maximum (+). Turn the TIME knob anti-clockwise on the minimum(-).
Turn the LUX knob clockwise on the maximun(sun).
• When you switch on the power, the light will be on at once, and 30-5 seconds later will be o automati-
cally. Then if the light receives induction signal, it can work normally
• A er 10sec of the first detection, the light could work again. If there is no induction signal, the load will
stopped working within 10sec.
• Turn the LUX knob anti-clockwise to minimum. If it is adjusted to 5LUX the load and the sensor should not
work when testing in daylight. If you cover the detection window with opaque object such as towel etc, the
load will work. Under no induction signal the load will stop working within 10 seconds.
