V-TAC VT-10-S Gebrauchsanweisung

TECHNICAL DATA
MODEL
SKU
LUMENS
POWER
BEAM ANGLE
INPUT VOLTAGE
ON/OFF CYCLE
LIFE SPAN
CRI
PF
BODY TYPE
DETECTION RANGE
INSTALLING HEIGHT
TIME DELAY
DETECTION DISTANCE
WORKING TEMPERATURE
DIMENSION
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions carefully
before starting the installation and keep this manual handy for future reference. If you have any another query, please
contact our dealer or local vendor from whom you have purchased the product. They are trained and ready to serve you
at the best. The warranty is valid for 5 years from the date of purchase. The warranty does not apply to damage caused by
incorrect installation or abnormal wear and tear. The company gives no warranty against damage to any surface due to
incorrect removal and installation of the product. The products are suitable for 10-12 Hours Daily operation. Usage of prod-
uct for 24 Hours a day would void the warranty. This product is warranted for manufacturing defects only.
INSTRUCTION MANUAL
LED FLOODLIGHT WITH PIR SENSOR
VT-10-S VT-20-S
433,434,435 448,449,450
800 Lm 1600 Lm
10W 20W
100°
AC: 220-240V, 50Hz
>15,000 Times
30,000 Hours
>80
>0.9
Diecast Aluminium
120°
1.8m-2.5m
Min. 12Sec ±3Sec
Max. 6min ±2min
2-8m (<24°C)
-20°C to +40°C
153.78x114.5x54.86 177.75x153x55.46 197.75x178x57.16 234.3x223x57.06
VT-30-S VT-50-S
457,458,459 466,467,468
2400 Lm 4000 Lm
30W 50W
WEEE Number: 80133970
