These operating instructions are an integral part of this product. They contain important information and safety notes,
and should therefore be kept in a safe place at all times. Be sure to pass them on to the new owner if you ever dispose of the
product.
1. S N
AFETY OTES
!
Read the instructions before using the controller
!
Avoid heat build-up
Provide unobstructed air circulation round the controller
!
Do not connect the flight battery with reversed polarity
Connecting the battery leads with reversed polarity will instantly wreck the controller
For this reason:
• red wire to the POSITIVE terminal (+)
• black wire to the NEGATIVE terminal (-)
!
When soldering or working on the motor or controller
Always disconnect the battery (short-circuit / injury hazard)
!
When testing and running the power system
Do not run the motor while holding it in your hand; always secure the model firmly. Check that there is adequate space for the
propeller to rotate. Remove all objects from the area around the propeller which could be sucked in or blown away (clothing, paper
etc.). Never stand in the rotational plane of the propeller (injury hazard).
2. S :
PECIFICATION
Type Idem no.
BL-60 SD # 72236
Maximum number of servos usable with MULTIcont BL-60 controllers in BEC mode**
MULTIcont
Maximum number of microservos*:
* MULTIPLEX Tiny-S servo types.
** If the number of servos in the model exceeds the stated maximum, it is essential to disable the BEC system and use a separate
receiver battery ( 7.).
3. S F
PECIAL EATURES
MULTIPLEX MULTIcont BL-60 SD controller offers an excellent range of additional features:
numerous programmable parameters
- low-voltage cut-off for: LiPo and NiXX batteries
- brake: ON or OFF
- motor reverse: on or off
- motor cut-off type: motor power reduction or motor cut
- motor start behaviour: soft or standard
- timing: automatic or manual (7 degrees or 22 - 30 degrees)
- model type: fixed-wing or helicopter (governor mode)
These parameters are programmable using the transmitter throttle stick.
!
But not with the MULTIPLEX MULTImate # 8 2094 or PC.
MULTIPLEX Modellsport GmbH & Co.KG • Westliche Gewerbestraße 1 • D-75015 Bretten • www.multiplex-rc.de
Operating instructions
MULTIcont BL-60 SD
Cont. Current Battery cell
(A) NiXX/Lipo
60A 5-18NC \ 2-6 Lipo
(80A burst)
BL-60
8
Weight BEC Size (mm)
(g) Output W*L*H
52 5.5V / 5A 31x57x14
User
Program
yes
